ECE-P1 Series

Manufacturer: Panasonic Industrial Automation Sales

Catalog

CAP ALUM 47000UF 20% 50V SNAP TH

Part	Ripple Current @ High Frequency	Mounting Type	Polarization	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Lifetime @ Temp.	Size / Dimension [diameter]	Size / Dimension [diameter]	Operating Temperature [Max]	Operating Temperature [Min]	Package / Case	ESR (Equivalent Series Resistance)	Applications	Lead Spacing	Lead Spacing	Capacitance	Voltage - Rated	Tolerance	Ripple Current @ Low Frequency	Height - Seated (Max)
Panasonic Industrial Automation Sales ECE-P1HP473HA	13.27 A	Through Hole	Polar	63 mm	2.48 in	3000 Hrs	1.969 in	50 mm	85 °C	-40 °C	Radial Can - Snap-In - 5 Lead	13 mOhm	General Purpose	25 mm	0.984 "	47 mF	50 VDC	20 %
Panasonic Industrial Automation Sales ECE-P1KA273HA	9.637 A	Through Hole	Polar	105 mm	4.134 "	3000 Hrs	1.969 in	50 mm	105 ░C	-40 °C	Radial Can - Snap-In - 5 Lead		General Purpose	25 mm	0.984 "	27000 µF	80 V	20 %
Panasonic Industrial Automation Sales ECE-P1HP823HA	15.95 A	Through Hole	Polar	105 mm	4.134 "	3000 Hrs	1.969 in	50 mm	85 °C	-40 °C	Radial Can - Snap-In - 5 Lead	11 mOhm	General Purpose	25 mm	0.984 "	82000 µF	50 VDC	20 %	13.87 A
Panasonic Industrial Automation Sales ECE-P1HP563HA	14.33 A	Through Hole	Polar	80 mm	3.15 in	3000 Hrs	1.969 in	50 mm	85 °C	-40 °C	Radial Can - Snap-In - 5 Lead	12 mOhm	General Purpose	25 mm	0.984 "	56000 µF	50 VDC	20 %	12.46 A
Panasonic Industrial Automation Sales ECE-P1KP223HA	12.74 A	Through Hole	Polar	63 mm	2.48 in	3000 Hrs	1.969 in	50 mm	85 °C	-40 °C	Radial Can - Snap-In - 5 Lead	19 mOhm	General Purpose	25 mm	0.984 "	22000 µF	80 V	20 %	11.08 A
Panasonic Industrial Automation Sales ECE-P1KA183HA	8.384 A	Through Hole	Polar	80 mm	3.15 in	3000 Hrs	1.969 in	50 mm	105 ░C	-40 °C	Radial Can - Snap-In - 5 Lead	26 mOhm	General Purpose	25 mm	0.984 "	18000 µF	80 V	20 %	7.29 A
Panasonic Industrial Automation Sales ECE-P1HA683HA	11.98 A	Through Hole	Polar	105 mm	4.134 "	3000 Hrs	1.969 in	50 mm	105 ░C	-40 °C	Radial Can - Snap-In - 5 Lead	11 mOhm	General Purpose	25 mm	0.984 "	68000 µF	50 VDC	20 %	10.42 A
Panasonic Industrial Automation Sales ECE-P1HA333HA	8.913 A	Through Hole	Polar			3000 Hrs	1.969 in	50 mm	105 ░C	-40 °C	Radial Can - Snap-In - 5 Lead	18 mOhm	General Purpose	25 mm	0.984 "	33000 µF	50 VDC	20 %	7.75 A
Panasonic Industrial Automation Sales ECE-P1HA393HA	9.66 A	Through Hole	Polar	63 mm	2.48 in	3000 Hrs	1.969 in	50 mm	105 ░C	-40 °C	Radial Can - Snap-In - 5 Lead	16 mOhm	General Purpose	25 mm	0.984 "	39000 µF	50 VDC	20 %
Panasonic Industrial Automation Sales ECE-P1KA223HA	9.005 A	Through Hole	Polar		3.622 in	3000 Hrs	1.969 in	50 mm	105 ░C	-40 °C	Radial Can - Snap-In - 5 Lead	22 mOhms	General Purpose	25 mm	0.984 "	22000 µF	80 V	20 %	7.83 A	92 mm
