M20-877 Series

Catalog

HEADERS & WIRE HOUSINGS 05 SIL VERTICAL SMT HEADER TIN

...

Part	Mated Stacking Heights	Number of Rows	Insulation Color	Contact Type	Connector Type	Contact Finish - Post	Style	Contact Shape	Operating Temperature [Min]	Operating Temperature [Max]	Number of Positions Loaded	Current Rating (Amps)	Contact Material	Insulation Height	Insulation Height	Shrouding	Insulation Material	Contact Length - Mating	Contact Length - Mating	Fastening Type	Material Flammability Rating	Termination	Mounting Type	Pitch - Mating	Pitch - Mating	Number of Positions	Features	Contact Finish - Mating
Harwin Inc. M20-8770546	11.63 mm 12.23 mm 12.63 mm 18.13 mm	1	Black	Male Pin	Header Cuttable	Tin	Board to Board Cable	Square	-40 C	105 ░C	All	3 A	Brass	0.1 in	2.54 mm	Unshrouded	Nylon 6T Polyamide (PA6T)	0.228 in	5.8 mm	Push-Pull	UL94 V-0	Solder	Surface Mount	0.1 "	2.54 mm	5
Harwin Inc. M20-8771046	11.63 mm 12.23 mm 12.63 mm 18.13 mm	1	Black	Male Pin	Header Cuttable	Tin	Board to Board Cable	Square	-40 C	105 ░C	All	3 A	Brass	0.1 in	2.54 mm	Unshrouded	Nylon 6T Polyamide (PA6T)	0.228 in	5.8 mm	Push-Pull	UL94 V-0	Solder	Surface Mount	0.1 "	2.54 mm	10
Harwin Inc. M20-8771042P	11.63 mm 12.23 mm 12.63 mm 18.13 mm	1	Black	Male Pin	Header Cuttable	Tin	Board to Board Cable	Square	-40 C	105 ░C	All	3 A	Brass	0.1 in	2.54 mm	Unshrouded	Nylon 6T Polyamide (PA6T)	0.228 in	5.8 mm	Push-Pull	UL94 V-0	Solder	Surface Mount	0.1 "	2.54 mm	10	Pick and Place	Gold
Harwin Inc. M20-8770642P	11.63 mm 12.23 mm 12.63 mm 18.13 mm	1	Black	Male Pin	Header Cuttable	Tin	Board to Board Cable	Square	-40 C	105 ░C	All	3 A	Brass	0.1 in	2.54 mm	Unshrouded	Nylon 6T Polyamide (PA6T)	0.228 in	5.8 mm	Push-Pull	UL94 V-0	Solder	Surface Mount	0.1 "	2.54 mm	6	Pick and Place	Gold
Harwin Inc. M20-8771142	11.63 mm 12.23 mm 12.63 mm 18.13 mm	1	Black	Male Pin	Header Cuttable	Tin	Board to Board Cable	Square	-40 C	105 ░C	All	3 A	Brass	0.1 in	2.54 mm	Unshrouded	Nylon 6T Polyamide (PA6T)	0.228 in	5.8 mm	Push-Pull	UL94 V-0	Solder	Surface Mount	0.1 "	2.54 mm	11		Gold
Harwin Inc. M20-8770646R	11.63 mm 12.23 mm 12.63 mm 18.13 mm	1	Black	Male Pin	Header Cuttable	Tin	Board to Board Cable	Square	-40 C	105 ░C	All	3 A	Brass	0.1 in	2.54 mm	Unshrouded	Nylon 6T Polyamide (PA6T)	0.228 in	5.8 mm	Push-Pull	UL94 V-0	Solder	Surface Mount	0.1 "	2.54 mm	6
Harwin Inc. M20-8772746	11.63 mm 12.23 mm 12.63 mm 18.13 mm	1	Black	Male Pin	Header Cuttable	Tin	Board to Board Cable	Square	-40 C	105 ░C	All	3 A	Brass	0.1 in	2.54 mm	Unshrouded	Nylon 6T Polyamide (PA6T)	0.228 in	5.8 mm	Push-Pull	UL94 V-0	Solder	Surface Mount	0.1 "	2.54 mm	27
Harwin Inc. M20-8772242P	11.63 mm 12.23 mm 12.63 mm 18.13 mm	1	Black	Male Pin	Header Cuttable	Tin	Board to Board Cable	Square	-40 C	105 ░C	All	3 A	Brass	0.1 in	2.54 mm	Unshrouded	Nylon 6T Polyamide (PA6T)	0.228 in	5.8 mm	Push-Pull	UL94 V-0	Solder	Surface Mount	0.1 "	2.54 mm	22	Pick and Place	Gold
Harwin Inc. M20-8771542R	11.63 mm 12.23 mm 12.63 mm 18.13 mm	1	Black	Male Pin	Header Cuttable	Tin	Board to Board Cable	Square	-40 C	105 ░C	All	3 A	Brass	0.1 in	2.54 mm	Unshrouded	Nylon 6T Polyamide (PA6T)	0.228 in	5.8 mm	Push-Pull	UL94 V-0	Solder	Surface Mount	0.1 "	2.54 mm	15		Gold
Harwin Inc. M20-8770346R	11.63 mm 12.23 mm 12.63 mm 18.13 mm	1	Black	Male Pin	Header Cuttable	Tin	Board to Board Cable	Square	-40 C	105 ░C	All	3 A	Brass	0.1 in	2.54 mm	Unshrouded	Nylon 6T Polyamide (PA6T)	0.228 in	5.8 mm	Push-Pull	UL94 V-0	Solder	Surface Mount	0.1 "	2.54 mm
