MSS1038 Series
Manufacturer: Coilcraft
Beta
⌘K
POWER INDUCTORS - SMD 68UH SHLD 20% 1.75A 213MOHMS
| Part | Tolerance | Type | DC Resistance (DCR) [Max] | Frequency - Self Resonant | Material - Core | Ratings | Mounting Type | Height - Seated (Max) | Height - Seated (Max) [Max] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [y] | Current - Saturation (Isat) | Current Rating (Amps) | Inductance | Inductance Frequency - Test | Shielding | Operating Temperature [Max] | Operating Temperature [Min] | Package / Case |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Coilcraft | 20 % | Drum Core | 213 mOhm | 10 MHz | Ferrite | AEC-Q200 | Surface Mount | 4 mm | 0.157 in | 10 mm | 10.2 mm | 0.402 in | 0.394 in | 1.32 A | 1.75 A | 68 µH | 100 kHz | Shielded | 85 °C | -40 C | Nonstandard |
Coilcraft | 20 % | Drum Core | 128 mOhm | 11 MHz | Ferrite | AEC-Q200 | Surface Mount | 4 mm | 0.157 in | 10 mm | 10.2 mm | 0.402 in | 0.394 in | 1.6 A | 2.2 A | 47 µH | 100 kHz | Shielded | 85 °C | -40 C | Nonstandard |
