T497 Series

Manufacturer: KEMET

Catalog

TANTALUM CAPACITORS - SOLID SMD 50V 1UF 10% ESR=6OHMS

Part	Features	Manufacturer Size Code	Package / Case	Operating Temperature [Min]	Operating Temperature [Max]	Failure Rate	Voltage - Rated	ESR (Equivalent Series Resistance)	Ratings	Capacitance	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Type	Lifetime @ Temp.	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Tolerance	Mounting Type	Package / Case	Size / Dimension [y]	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]
KEMET T497E105K050BB6115	High Reliability	E	2010 (5025 Metric)	-55 C	125 °C	B	50 VDC	6 Ohm	COTS	1 µF	0.065 "	1.65 mm	Molded	2000 Hrs	0.1 in	5.08 mm	2.54 mm	0.2 in	10 %	Surface Mount
KEMET T497X156K035CH612A	High Reliability	X	2721	-55 C	125 °C	C	35 V	190 mOhm		15 µF	0.123 "	3.12 mm	Molded	2000 Hrs	0.213 "	6.93 mm	5.41 mm	0.273 "	10 %	Surface Mount	6954 Metric
KEMET T497B105K025BH6110	High Reliability	B	1505	-55 C	125 °C	B	25 VDC	10 Ohm	COTS	1 µF	0.065 "	1.65 mm	Molded	2000 Hrs	0.05 in	3.81 mm		0.15 "	10 %	Surface Mount	3813 Metric	1.27 mm
KEMET T497G336M010AH6110	High Reliability	G	2711	-55 C	125 °C		10 V	1.5 Ohm	COTS	33 ÁF			Molded	2000 Hrs	0.11 "	6.73 mm	2.79 mm	0.265 in	20 %	Surface Mount	6728 Metric		3.17 mm	0.125 in
KEMET T497H106K035CH612A	High Reliability	H	2915 (7338 Metric)	-55 C	125 °C	C	35 V	500 mOhm		10 µF			Molded	2000 Hrs		0.285 in 7.24 mm	0.15 in 3.81 mm		10 %	Surface Mount			3.17 mm	0.125 in
KEMET T497H227K010CH612A	High Reliability	H	2915 (7338 Metric)	-55 C	125 °C	C	10 V	180 mOhm		220 µF			Molded	2000 Hrs		0.285 in 7.24 mm	0.15 in 3.81 mm		10 %	Surface Mount			3.17 mm	0.125 in
