1617748 Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
POWER RELAY 6VDC 10A DPDT(45.4MM) FLANGE
| Part | Coil Resistance | Mounting Type | Termination Style | Features | Operating Temperature [Min] | Operating Temperature [Max] | Coil Type | Seal Rating | Operate Time | Release Time | Contact Material | Must Release Voltage | Contact Rating (Current) | Contact Form | Must Operate Voltage | Coil Current | Switching Voltage [Max] | Relay Type | Coil Voltage | Load - Max Switching | Qualification | Grade |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | 20 Ohms | Chassis Mount | PC Pin | Diode | -70 °C | 125 °C | Non Latching | Sealed - Hermetically | 10 ms | 10 ms | Silver Cadmium Oxide (AgCdO) | 0.3 VDC | 10 A | DPDT (2 Form C) | 4.5 VDC | 300 mA | 28 VDC 115 VAC | General Purpose | ||||
 TE Connectivity AMP Connectors | ||||||||||||||||||||||
TE Connectivity AMP Connectors | ||||||||||||||||||||||
TE Connectivity AMP Connectors | 320 Ohms | Chassis Mount | PC Pin | Diode | -70 °C | 125 °C | Non Latching | Sealed - Hermetically | 10 ms | 10 ms | Silver Cadmium Oxide (AgCdO) | 1.5 VDC | 10 A | DPDT (2 Form C) | 18 VDC | 87.5 mA | 28 VDC 115 VAC | General Purpose | 28 VDC | |||
 TE Connectivity AMP Connectors | 320 Ohms | Chassis Mount | Solder Hook | -70 °C | 125 °C | Non Latching | Sealed - Hermetically | 10 ms | 10 ms | Silver Cadmium Oxide (AgCdO) | 2.3 VDC | 25 A | SPDT (1 Form C) | 13.5 VDC | 875 mA | 28 VDC 115 VAC | General Purpose | 28 VDC | 700 W 2875 VA | MIL-R-6106/19 | Military | |
TE Connectivity AMP Connectors | 80 Ohms | Chassis Mount | Solder Hook | -70 °C | 125 °C | Non Latching | Sealed - Hermetically | 10 ms | 10 ms | Silver Cadmium Oxide (AgCdO) | 0.75 VDC | 25 A | SPDT (1 Form C) | 9 VDC | 0.15 A | 28 VDC 115 VAC | General Purpose | 12 VDC | 700 W 2875 VA | |||
TE Connectivity AMP Connectors | 320 Ohms | Chassis Mount | PC Pin | Diode | -70 °C | 125 °C | Non Latching | Sealed - Hermetically | 10 ms | 10 ms | Silver Cadmium Oxide (AgCdO) | 1.5 VDC | 25 A | SPDT (1 Form C) | 18 VDC | 87.5 mA | 28 VDC 115 VAC | General Purpose | 28 VDC | 700 W 2875 VA | ||
TE Connectivity AMP Connectors | 320 Ohms | Chassis Mount | PC Pin | -70 °C | 125 °C | Non Latching | Sealed - Hermetically | 10 ms | 10 ms | Silver Cadmium Oxide (AgCdO) | 1.5 VDC | 10 A | DPDT (2 Form C) | 18 VDC | 87.5 mA | General Purpose | 28 VDC | |||||
TE Connectivity AMP Connectors | 20 Ohms | Chassis Mount | PC Pin | Diode | -70 °C | 125 °C | Non Latching | Sealed - Hermetically | 10 ms | 10 ms | Silver Cadmium Oxide (AgCdO) | 0.3 VDC | 10 A | DPDT (2 Form C) | 4.5 VDC | 300 mA | 28 VDC 115 VAC | General Purpose |
