SR Series
Manufacturer: YAGEO
Beta
⌘K
THICK FILM RESISTORS - SMD 2.2 KOHMS 1/4 W 0805 5 % AEC-Q200
| Part | Height - Seated (Max) [Max] | Height - Seated (Max) [Max] | Composition | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | Supplier Device Package | Temperature Coefficient | Number of Terminations [custom] | Operating Temperature [Max] | Operating Temperature [Min] | Power (Watts) | Power (Watts) | Package / Case | Features | Tolerance | Resistance | Ratings | Supplier Device Package | Package / Case | Power (Watts) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 YAGEO | 0.6 mm | 0.024 in | Thick Film | 2 mm | 1.25 mm | 0.049 " | 0.079 in | 0805 | 100 ppm/°C | 2 | 155 C | -55 C | 0.25 W | 0.25 W | 0805 | Automotive AEC-Q200 Pulse Withstanding | 5 % | 2200 Ohms | ||||
 YAGEO | 0.65 mm | 0.026 in | Thick Film | 3.1 mm | 1.6 mm | 0.063 " | 0.122 " | 1206 | 100 ppm/°C | 2 | 155 C | -55 C | 0.5 W | 0.5 W | 1206 (3216 Metric) | Automotive AEC-Q200 Pulse Withstanding | 5 % | 1.2 kOhms | AEC-Q200 | |||
 YAGEO | 0.65 mm | 0.026 in | Thick Film | 6.35 mm | 3.1 mm | 0.122 in | 0.25 in | 100 ppm/°C | 2 | 155 C | -55 C | 1 W | 2512 (6432 Metric) | Automotive AEC-Q200 Pulse Withstanding | 20 % | 270 Ohms | AEC-Q200 | 2512 | ||||
YAGEO | 0.6 mm | 0.024 in | Thick Film | 2 mm | 1.25 mm | 0.049 " | 0.079 in | 0805 | 100 ppm/°C | 2 | 155 C | -55 C | 0.125 W | 0.125 W | 0805 | Automotive AEC-Q200 Pulse Withstanding | 1 % | 51 kOhms | AEC-Q200 | |||
 YAGEO | 0.65 mm | 0.026 in | Thick Film | 6.35 mm | 3.1 mm | 0.122 in | 0.25 in | 200 ppm/°C | 2 | 155 C | -55 C | 1 W | 2512 | Automotive AEC-Q200 Pulse Withstanding | 10 % | 1.2 Ohms | 2512 | 6332 Metric | ||||
 YAGEO | 0.65 mm | 0.026 in | Thick Film | 3.1 mm | 1.6 mm | 0.063 " | 0.122 " | 1206 | 100 ppm/°C | 2 | 155 C | -55 C | 0.75 W | 1206 (3216 Metric) | Automotive AEC-Q200 Pulse Withstanding | 1 % | 22 Ohms | 3/4W | ||||
 YAGEO | 0.65 mm | 0.026 in | Thick Film | 5 mm | 2.5 mm | 0.098 in | 0.197 in | 200 ppm/°C | 2 | 155 C | -55 C | 0.75 W | 2010 (5025 Metric) | Automotive AEC-Q200 Pulse Withstanding | 10 % | 5.6 Ohms | AEC-Q200 | 2010 | 3/4W | |||
YAGEO | 0.65 mm | 0.026 in | Thick Film | 6.35 mm | 3.1 mm | 0.122 in | 0.25 in | 200 ppm/°C | 2 | 155 C | -55 C | 1 W | 2512 (6432 Metric) | Automotive AEC-Q200 Pulse Withstanding | 1 % | AEC-Q200 | 2512 | |||||
YAGEO | 0.6 mm | 0.024 in | Thick Film | 2 mm | 1.25 mm | 0.049 " | 0.079 in | 0805 | 100 ppm/°C | 2 | 155 C | -55 C | 0.5 W | 0.5 W | 0805 | Automotive AEC-Q200 Pulse Withstanding | 1 % | 62 Ohms | AEC-Q200 | |||
YAGEO | 0.65 mm | 0.026 in | Thick Film | 5 mm | 2.5 mm | 0.098 in | 0.197 in | 100 ppm/°C | 2 | 155 C | -55 C | 0.75 W | 2010 (5025 Metric) | Automotive AEC-Q200 Pulse Withstanding | 10 % | 33000 Ohms | AEC-Q200 | 2010 | 3/4W |
