MDS15 Series

Catalog

DC DC CONVERTER 12V 15W

Part	Number of Outputs	Package / Case	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [z]	Power (Watts)	Voltage - Input (Max) [Max]	Mounting Type	Voltage - Output 1	Operating Temperature [Max]	Operating Temperature [Min]	Type	Current - Output (Max) [Max]	Applications	Voltage - Input (Min) [Min]	Approval Agency	Voltage - Isolation	Efficiency
MEAN WELL USA Inc. MDS15A-12	1	5-DIP Module	25.4 mm	0.47 "	1 "	50.8 mm	2 in	12 mm	15 W	18 V	Through Hole	12 V	90 °C	-40 °C	Isolated Module	1.25 A	Medical	9 V	CE EAC	4000 V	88 %
MEAN WELL USA Inc. MDS15A-15	1	5-DIP Module	25.4 mm	0.47 "	1 "	50.8 mm	2 in	12 mm	15 W	18 V	Through Hole	15 V	90 °C	-40 °C	Isolated Module	1 A	Medical	9 V	CE EAC	4000 V	87 %
