C40 Series
Manufacturer: XP Power
Beta
⌘K
HIGH VOLTAGE DC/DC CONVERTER, REGULATED, NEGATIVE OUTPUT, FIXED, ADJUSTABLE, 1 W, 250 ΜA
| Part | Voltage - Output 1 | Applications | Operating Temperature [Min] | Operating Temperature [Max] | Mounting Type | Package / Case | Type | Features | Current - Output (Max) [Max] | Standard Number | Number of Outputs | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | Voltage - Input (Max) [Max] | Voltage - Input (Min) [Min] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 XP Power | -4000 V | ITE (Commercial) | -10 °C | 60 °C | Through Hole | 5-DIP Module | High Voltage - Non-Isolated Module | SCP | 250 µA | 62368-1 | 1 | 0.5 in | 44.5 mm | 12.7 mm | 28.2 mm | 1.11 in | 1.75 " | 16 V | 11.5 V |
