GPS15 Series

Catalog

RF ANT 1.575GHZ MOD CAB ADH .43"

Part	RF Family/Standard	Frequency Group [Max]	Frequency Group [Min]	Frequency Group	Frequency (Center/Band)	Ingress Protection	Number of Bands	Frequency Range [Max]	Frequency Range [Min]	Termination	Height (Max) [Max] [z]	Height (Max)	Antenna Type	Gain	VSWR	Features	Mounting Type	Applications
TE Connectivity AMP Connectors GPS15MGSMB	Navigation	2 GHz	1 GHz	UHF	1.575 GHz	IP67	1	1.576 GHz	1.574 GHz	SMB Male	0.43 in	10.92 mm	Module	26 dBi	2	Cable - 4.6m	Adhesive Magnetic	GPS
TE Connectivity AMP Connectors GPS15MGSMA	Navigation	2 GHz	1 GHz	UHF	1.575 GHz	IP67	1	1.576 GHz	1.574 GHz		0.43 in	10.92 mm	Module	26 dBi	2	Cable - 4.6m	Adhesive Magnetic	GPS
TE Connectivity AMP Connectors GPS15MGSMA	Navigation	2 GHz	1 GHz	UHF	1.575 GHz	IP67	1	1.576 GHz	1.574 GHz		0.43 in	10.92 mm	Module	26 dBi	2	Cable - 4.6m	Adhesive Magnetic	GPS
TE Connectivity AMP Connectors GPS15MGTN	Navigation	2 GHz	1 GHz	UHF	1.575 GHz	IP67	1	1.576 GHz	1.574 GHz	TNC Male	0.43 in	10.92 mm	Module	26 dBi	2	Cable - 4.6m	Adhesive Magnetic	GPS
TE Connectivity AMP Connectors GPS15MGTN	Navigation	2 GHz	1 GHz	UHF	1.575 GHz	IP67	1	1.576 GHz	1.574 GHz	TNC Male	0.43 in	10.92 mm	Module	26 dBi	2	Cable - 4.6m	Adhesive Magnetic	GPS
TE Connectivity AMP Connectors GPS15MGSMB	Navigation	2 GHz	1 GHz	UHF	1.575 GHz	IP67	1	1.576 GHz	1.574 GHz	SMB Male	0.43 in	10.92 mm	Module	26 dBi	2	Cable - 4.6m	Adhesive Magnetic	GPS
