tl6120 Series
Manufacturer: E-Switch
Beta
⌘K
MICROSWITCH TACT; SPST-NO; POS: 2; 0.05A/12VDC; SMT; NONE; 5N; 4.7MM
| Part | Termination Style | Outline [y] | Outline [x] | Operating Temperature [Max] | Operating Temperature [Min] | Switch Function | Operating Force | Circuit | Contact Rating @ Voltage | Actuator Height off PCB, Vertical [z] | Actuator Type | Illumination | Mounting Type | Actuator Orientation |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 E-Switch | Gull Wing | 7.4 mm | 7.4 mm | 85 °C | -40 C | Off-Mom | 0.5 kgf | SPST-NO | 0.05 A 12 VDC | 4.7 mm | Standard | Non-Illuminated | Surface Mount | Top Actuated |
 E-Switch | Gull Wing | 7.4 mm | 7.4 mm | 85 °C | -40 C | Off-Mom | 300 gf | SPST-NO | 0.05 A 12 VDC | 4.7 mm | Standard | Non-Illuminated | Surface Mount | Top Actuated |
