SDE6603 Series

Catalog

FIXED IND 33UH 600MA 510MOHM SMD

Part	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Mounting Type	Inductance	Inductance Frequency - Test	Frequency - Self Resonant	Material - Core	Current - Saturation (Isat)	DC Resistance (DCR) [Max]	Shielding	Type	Package / Case	Current Rating (Amps)	Tolerance	Operating Temperature [Max]	Operating Temperature [Min]	DC Resistance (DCR)
Bourns Inc. SDE6603-330M	0.26 in	4.45 mm	0.175 "	6.6 mm	Surface Mount	33 µH	100 kHz	15 MHz	Ferrite	580 mA	510 mOhm	Unshielded	Drum Core Wirewound	Nonstandard	600 mA	20 %	105 ░C	-25 °C
Bourns Inc. SDE6603-681M	0.26 in	4.45 mm	0.175 "	6.6 mm	Surface Mount	680 µH	100 kHz	3 MHz	Ferrite	140 mA		Unshielded	Drum Core Wirewound	Nonstandard	120 mA	20 %	105 ░C	-25 °C	9.2 Ohm
Bourns Inc. SDE6603-100M	0.26 in	4.45 mm	0.175 "	6.6 mm	Surface Mount	10 µH	100 kHz	35 MHz	Ferrite	1.1 A	160 mOhm	Unshielded	Drum Core Wirewound	Nonstandard	1.1 A	20 %	105 ░C	-25 °C
Bourns Inc. SDE6603-331M	0.26 in	4.45 mm	0.175 "	6.6 mm	Surface Mount	330 µH	100 kHz	5 MHz	Ferrite	180 mA	3.8 Ohm	Unshielded	Drum Core Wirewound	Nonstandard	160 mA	20 %	105 ░C	-25 °C
Bourns Inc. SDE6603-2R2M	0.26 in	4.45 mm	0.175 "	6.6 mm	Surface Mount	2.2 µH	100 kHz	90 MHz	Ferrite	2.3 A		Unshielded	Drum Core Wirewound	Nonstandard	2.4 A	20 %	105 ░C	-25 °C	70 mOhm
Bourns Inc. SDE6603-4R7M	0.26 in	4.45 mm	0.175 "	6.6 mm	Surface Mount	4.7 ÁH	100 kHz	50 MHz	Ferrite		90 mOhm	Unshielded	Drum Core Wirewound	Nonstandard	1.5 A	20 %	105 ░C	-25 °C
Bourns Inc. SDE6603-221M	0.26 in	4.45 mm	0.175 "	6.6 mm	Surface Mount	220 µH	100 kHz	5.5 MHz	Ferrite	220 mA	3.11 Ohm	Unshielded	Drum Core Wirewound	Nonstandard	0.2 A	20 %	105 ░C	-25 °C
