C4BS Series

Manufacturer: KEMET

Catalog

FILM CAPACITORS 3000VOLTS 0.1UF 5%

Part	Voltage Rating - AC	Tolerance	Dielectric Material	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Termination	Package / Case	Lead Spacing	Lead Spacing	Operating Temperature [Max]	Operating Temperature [Min]	Mounting Type	Applications	Capacitance	Voltage Rating - DC	Voltage Rating - DC	ESR (Equivalent Series Resistance)	Size / Dimension [y]	Size / Dimension [x]	Height - Seated (Max)	Height - Seated (Max)
KEMET C4BSYBX3100ZA0J	750 V	5 %	Polypropylene (PP) Metallized	41.5 mm	1.634 in	20 mm	0.787 in	47.5 mm	1.87 in	Screw Terminals	Rectangular Box	0.866 "	22 mm	85 °C	-40 C	Chassis Mount	DC Filtering DC Link Snubber	100000 pF	3 kV	3000 V	17.3 mOhms
KEMET C4BSNBX4150ZFJJ	600 V	5 %	Polypropylene (PP) Metallized	42.5 mm	1.673 "		1.102 "	37.2 mm	1.465 in	Screw Terminals	Rectangular Box	0.866 "	22 mm	85 °C	-40 C	Chassis Mount	DC Filtering DC Link High Frequency Snubber Switching	1500 nF	1 kV	1 kVDC	2.5 mOhms	28 mm
KEMET C4BSPBX4330ZANJ	630 V	5 %	Polypropylene (PP) Metallized	2.264 in		1.378 in				Screw Terminals	Rectangular Box	1.614 in	41 mm	85 °C	-40 C	Chassis Mount	DC Filtering DC Link High Frequency Snubber Switching	3.3 µF	1.2 kV	1200 V	2.3 mOhms	35 mm	57.5 mm
KEMET C4BSWBX4120ZBMJ	700 V	5 %	Polypropylene (PP) Metallized	57.5 mm	2.264 in	30 mm	1.181 in			Screw Terminals	Rectangular Box	1.457 "	37 mm	85 °C	-40 C	Chassis Mount	DC Filtering DC Link High Frequency Snubber Switching	1.2 µF	2 kV	2 kVDC	4.3 mOhm			1.783 in	45.3 mm
KEMET C4BSWBX3220ZBFJ	700 V	5 %	Polypropylene (PP) Metallized	41.5 mm	1.634 in	20 mm	0.787 in	40.2 mm	1.583 in	Screw Terminals	Rectangular Box	0.866 "	22 mm	85 °C	-40 C	Chassis Mount	DC Filtering DC Link High Frequency Snubber Switching	0.22 µF	2 kV	2 kVDC	10.7 mOhms
