MAX11613 Series

Catalog

IC ADC 12BIT SAR 8UMAX

Part	Package / Case	Package / Case [custom]	Package / Case	Ratio - S/H:ADC	Operating Temperature [Max]	Operating Temperature [Min]	Architecture	Input Type	Data Interface	Voltage - Supply, Analog [Min]	Voltage - Supply, Analog [Max]	Configuration	Reference Type	Number of Inputs	Sampling Rate (Per Second)	Number of Bits	Voltage - Supply, Digital [Max]	Voltage - Supply, Digital [Min]	Number of A/D Converters	Mounting Type	Supplier Device Package	Supplier Device Package [x]	Supplier Device Package [y]	Utilized IC / Part	Supplied Contents
Analog Devices Inc./Maxim Integrated MAX11613EUA+T	8-MSOP 8-TSSOP	0.118 in	3 mm	1:1	85 °C	-40 °C	SAR	Differential Single Ended	I2C	2.7 V	3.6 V	MUX-S/H-ADC	External Internal	2 4	94.4 k per second	12 bits	3.6 V	2.7 V	1	Surface Mount	8-uMAX/uSOP
Analog Devices Inc./Maxim Integrated MAX11613EWC+T	12-WFBGA WLBGA			1:1	85 °C	-40 °C	SAR	Differential Single Ended	I2C	2.7 V	3.6 V	MUX-S/H-ADC	External Internal	2 4	94.4 k per second	12 bits	3.6 V	2.7 V	1	Surface Mount	12-WLP	2.14	1.56
Analog Devices Inc./Maxim Integrated MAX11613EVSYS+									I2C Serial						94.4 k per second	8 10 12			1					MAX11613	Board(s)
Analog Devices Inc./Maxim Integrated MAX11613EUA+	8-MSOP 8-TSSOP	0.118 in	3 mm	1:1	85 °C	-40 °C	SAR	Differential Single Ended	I2C	2.7 V	3.6 V	MUX-S/H-ADC	External Internal	2 4	94.4 k per second	12 bits	3.6 V	2.7 V	1	Surface Mount	8-uMAX/uSOP
