RSAN Series

Catalog

CONDITIONER, 250 V, RSAN SERIES, 87 MM, 52 MM

Part	Mounting Type	Configuration	Applications	Voltage - Rated AC	Current	Voltage - Rated DC	Termination Style	Approval Agency	Filter Type	Operating Temperature [Max]	Operating Temperature [Min]
TDK Corporation RSAN-2006D	DIN Rail	Single Stage	General Purpose	250 V	6 A	250 V	Terminal Block	CSA EN UL	Single Phase	85 °C	-25 °C
TDK Corporation RSAN-2006LD	DIN Rail	Single Stage	General Purpose	250 V	6 A	250 V	Terminal Block	CSA EN UL	Single Phase	85 °C	-25 °C
TDK Corporation RSAN-2003D	DIN Rail	Single Stage	General Purpose	250 V	3 A	250 V	Terminal Block	CSA EN UL	Single Phase	85 °C	-25 °C
TDK Corporation RSAN-2010	Chassis Mount	Single Stage	General Purpose	250 V	10 A	250 V	Terminal Block	CSA EN UL	Single Phase	85 °C	-25 °C
TDK Corporation RSAN-2030	Chassis Mount	Single Stage	General Purpose	250 V	30 A	250 V	Terminal Block	CSA EN UL	Single Phase	85 °C	-25 °C
TDK Corporation RSAN-2016D	DIN Rail	Single Stage	General Purpose	250 V	16 A	250 V	Terminal Block	CSA EN UL	Single Phase	85 °C	-25 °C
TDK Corporation RSAN-2020	Chassis Mount	Single Stage	General Purpose	250 V	20 A	250 V	Terminal Block	CSA EN UL	Single Phase	85 °C	-25 °C
TDK Corporation RSAN-2060	Chassis Mount	Single Stage	General Purpose	250 V	60 A	250 V	Terminal Block	CSA EN UL	Single Phase	85 °C	-25 °C
TDK Corporation RSAN-2016LD	DIN Rail	Single Stage	General Purpose	250 V	16 A	250 V	Terminal Block	CSA EN UL	Single Phase	85 °C	-25 °C
TDK Corporation RSAN-2006L	Chassis Mount	Single Stage	General Purpose	250 V	6 A	250 V	Terminal Block	CSA EN UL	Single Phase	85 °C	-25 °C
