396-043 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 43POS 0.125
| Part | Material - Insulation | Termination Rows | Gender | Pitch | Pitch | Number of Positions | Contact Type | Flange Feature [diameter] | Flange Feature [diameter] | Operating Temperature [Min] | Operating Temperature [Max] | Card Type | Mounting Type | Termination | Contact Finish | Contact Finish Thickness | Contact Finish Thickness | Color | Card Thickness [Max] | Card Thickness [Min] | Read Out | Contact Material | Number of Positions/Bay/Row | Number of Rows | Flange Feature | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 1 | Female | 3.18 mm | 0.125 in | 43 | Cantilever | 0.156 " | 3.96 mm | -40 C | 105 ░C | Non Specified - Single Edge | Right Angle Through Hole | Solder Wire Wrap | Gold | 0.25 Ám | 10 Áin | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Copper Alloy | 43 | 1 | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Female | 3.18 mm | 0.125 in | 43 | Cantilever | -40 C | 105 ░C | Non Specified - Single Edge | Right Angle Through Hole | Solder Wire Wrap | Gold | 0.25 Ám | 10 Áin | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Copper Alloy | 43 | 1 | M3 Threaded Insert Top Mount Opening | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Female | 3.18 mm | 0.125 in | 43 | Cantilever | -40 C | 105 ░C | Non Specified - Single Edge | Through Hole | Wire Wrap | Gold | 0.25 Ám | 10 Áin | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Copper Alloy | 43 | 1 | 4-40 Threaded Insert Top Mount Opening | Card Guides | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Female | 3.18 mm | 0.125 in | 43 | Cantilever | 0.128 " | 3.25 mm | -40 C | 105 ░C | Non Specified - Single Edge | Right Angle Through Hole | Solder Wire Wrap | Gold | 0.25 Ám | 10 Áin | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Copper Alloy | 43 | 1 | Flush Mount Side Opening Unthreaded | |
 EDAC Inc. | Polyester Thermoplastic | 1 | Female | 3.18 mm | 0.125 in | 43 | Cantilever | 0.128 " | 3.25 mm | -40 C | 105 ░C | Non Specified - Single Edge | Through Hole | Solder | Gold | 0.25 Ám | 10 Áin | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Copper Alloy | 43 | 1 | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Female | 3.18 mm | 0.125 in | 43 | Cantilever | -40 C | 105 ░C | Non Specified - Single Edge | Right Angle Through Hole | Solder Wire Wrap | Gold | 0.25 Ám | 10 Áin | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Copper Alloy | 43 | 1 | 4-40 Threaded Insert Top Mount Opening | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Female | 3.18 mm | 0.125 in | 43 | Cantilever | -40 C | 105 ░C | Non Specified - Single Edge | Through Hole | Solder | Gold | 0.25 Ám | 10 Áin | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Copper Alloy | 43 | 1 | Flush Mount M3 Threaded Insert Top Opening | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Female | 3.18 mm | 0.125 in | 43 | Cantilever | -40 C | 105 ░C | Non Specified - Single Edge | Through Hole | Wire Wrap | Gold | 0.25 Ám | 10 Áin | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Copper Alloy | 43 | 1 | 4-40 Threaded Insert Top Mount Opening | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Female | 3.18 mm | 0.125 in | 43 | Cantilever | 0.156 " | 3.96 mm | -40 C | 105 ░C | Non Specified - Single Edge | Through Hole | Solder | Gold | 0.25 Ám | 10 Áin | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Copper Alloy | 43 | 1 | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Female | 3.18 mm | 0.125 in | 43 | Cantilever | -40 C | 105 ░C | Non Specified - Single Edge | Through Hole | Solder | Gold | 0.25 Ám | 10 Áin | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Copper Alloy | 43 | 1 |
