ASEM1 Series

Catalog

STANDARD CLOCK OSCILLATORS OSCILLATOR 3225 4-SMD 48MHZ +/-50PPM -40°C ~ 85°C CMOS 3.3V

Part	Current - Supply (Disable) (Max)	Base Resonator	Frequency Stability	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Type	Mounting Type	Frequency	Voltage - Supply	Supplier Device Package [x]	Supplier Device Package [y]	Supplier Device Package	Operating Temperature [Max]	Operating Temperature [Min]	Function	Current - Supply (Max) [Max]	Output	Package / Case
Abracon LLC ASEM1-48.000MHZ-LC-T	1 µA	MEMS	50 ppm	2.5 mm	0.098 in	3.2 mm	0.126 "	0.035 in	0.9 mm	XO (Standard)	Surface Mount	48 MHz	3.3 V	3.2	2.5	4-SMD	85 °C	-40 C	Standby (Power Down)	15 mA	CMOS	4-SMD No Lead
Abracon LLC ASEM1-8.000MHZ-LC-T	1 µA	MEMS	50 ppm	2.5 mm	0.098 in	3.2 mm	0.126 "	0.035 in	0.9 mm	XO (Standard)	Surface Mount	8 MHz	3.3 V	3.2	2.5	4-SMD	85 °C	-40 C	Standby (Power Down)	15 mA	CMOS	4-SMD No Lead
Abracon LLC ASEM1-16.000MHZ-LC-T	1 µA	MEMS	50 ppm	2.5 mm	0.098 in	3.2 mm	0.126 "	0.035 in	0.9 mm	XO (Standard)	Surface Mount	16 MHz	3.3 V	3.2	2.5	4-SMD	85 °C	-40 C	Standby (Power Down)	15 mA	CMOS	4-SMD No Lead
Abracon LLC ASEM1-18.432MHZ-LC-T		MEMS	50 ppm	2.5 mm	0.098 in	3.2 mm	0.126 "	0.035 in	0.9 mm	XO (Standard)	Surface Mount	18.432 MHz	3.3 V	3.2	2.5	4-SMD	85 °C	-40 C	Standby (Power Down)	15 mA	CMOS	4-SMD No Lead
Abracon LLC ASEM1-50.000MHZ-LC-T	1 µA	MEMS	50 ppm	2.5 mm	0.098 in	3.2 mm	0.126 "	0.035 in	0.9 mm	XO (Standard)	Surface Mount	50 MHz	3.3 V	3.2	2.5	4-SMD	85 °C	-40 C	Standby (Power Down)	15 mA	CMOS	4-SMD No Lead
