896-030 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 30POS 0.125
| Part | Termination Rows [custom] | Material - Insulation | Mounting Type | Number of Rows [custom] | Number of Positions | Operating Temperature [Max] | Operating Temperature [Min] | Gender | Contact Type | Color | Card Thickness [Max] | Card Thickness [Min] | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Card Type | Number of Positions/Bay/Row | Termination | Contact Finish | Pitch | Pitch | Contact Finish Thickness | Contact Finish Thickness | Contact Material | Read Out | Termination Rows | Number of Rows | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Right Angle Through Hole | 2 | 30 | 125 °C | -40 C | Female | Cantilever | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | Non Specified - Dual Edge | 15 | Solder | Gold | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Copper Alloy | Dual | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Right Angle Through Hole | 30 | 125 °C | -40 C | Female | Cantilever | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | M3 Threaded Insert Top Mount Opening | Non Specified - Single Edge | 30 | Solder | Gold | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Copper Alloy | Single | 1 | 1 | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Right Angle Through Hole | 30 | 125 °C | -40 C | Female | Cantilever | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Non Specified - Single Edge | 30 | Solder | Gold | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Copper Alloy | Single | 1 | 1 | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Through Hole | 30 | 125 °C | -40 C | Female | Cantilever | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | M3 Threaded Insert Top Mount Opening | Non Specified - Single Edge | 30 | Wire Wrap | Gold | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Copper Alloy | Single | 1 | 1 | |||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Through Hole | 2 | 30 | 125 °C | -40 C | Female | Cantilever | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 4-40 Threaded Insert Top Mount Opening | Non Specified - Dual Edge | 15 | Solder | Gold | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Copper Alloy | Dual | |||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Through Hole | 2 | 30 | 125 °C | -40 C | Female | Cantilever | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Non Specified - Dual Edge | 15 | Wire Wrap | Gold | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Copper Alloy | Dual | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Board Edge Straddle Mount | 2 | 30 | 125 °C | -40 C | Female | Cantilever | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 4-40 Threaded Insert Top Mount Opening | Non Specified - Dual Edge | 15 | Solder | Gold | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Copper Alloy | Dual | Card Extender | ||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Through Hole | 2 | 30 | 125 °C | -40 C | Female | Cantilever | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.156 " | 3.96 mm | Non Specified - Dual Edge | 15 | Solder | Gold | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Copper Alloy | Dual | ||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Right Angle Through Hole | 2 | 30 | 125 °C | -40 C | Female | Cantilever | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.156 " | 3.96 mm | Non Specified - Dual Edge | 15 | Solder | Gold | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Copper Alloy | Dual | ||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Through Hole | 2 | 30 | 125 °C | -40 C | Female | Cantilever | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | Non Specified - Dual Edge | 15 | Solder | Gold | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Copper Alloy | Dual |
