31514 Series

Catalog

HOOK-UP STRND 14AWG BLACK

Part	Cable Type	Ratings	Voltage	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Material	Jacket Color	Length	Length	Wire Gauge	Conductor Material	Conductor Strand [custom]	Conductor Strand [custom]
Belden Inc. 31514 0104000	Hook-Up	UL Style 3046	600 V	1.19 mm	0.047 in	0.169 in	4.29 mm	Neoprene	Black	4000 '	1219.2 m	14.5 AWG	Copper Tinned	41	30
Belden Inc. 31514 010500	Hook-Up	UL Style 3046	600 V	1.19 mm	0.047 in	0.169 in	4.29 mm	Neoprene	Black	500 ft	152.4 m	14.5 AWG	Copper Tinned	41	30
Belden Inc. 31514 0044000	Hook-Up	UL Style 3046	600 V	1.19 mm	0.047 in	0.169 in	4.29 mm	Neoprene	Yellow	4000 '	1219.2 m	14.5 AWG	Copper Tinned	41	30
