3025-1511 Series
Manufacturer: Radiall USA, Inc.
Beta
⌘K
SLB / EDGE CARD PLUG FEMALE GOLD
| Part | Body Material | Center Contact Plating | Body Finish | Dielectric Material | Shield Termination | Number of Ports | Connector Style | Center Contact Material | Connector Type | Housing Color | Mounting Type | Contact Termination | Fastening Type | Mating Cycles | Insertion Loss | Operating Temperature [Min] | Operating Temperature [Max] | Impedance | Frequency - Max [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Radiall USA, Inc. | Brass | Gold | Gold | Polytetrafluoroethylene (PTFE) | Solder | 1 | SLB | Beryllium Copper | Female Socket Plug | Gold | Board Edge End Launch | Solder | Snap-On | ||||||
 Radiall USA, Inc. | Brass | Gold | Gold | Polytetrafluoroethylene (PTFE) | Solder | 1 | SLB | Beryllium Copper | Female Socket Plug | Gold | Through Hole | Solder | Snap-On | ||||||
 Radiall USA, Inc. | Brass | Gold | Gold | Polytetrafluoroethylene (PTFE) | Solder | 1 | SLB | Beryllium Copper | Female Socket Plug | Gold | Through Hole | Solder | Snap-On | ||||||
Radiall USA, Inc. | Brass | Gold | Gold | Polytetrafluoroethylene (PTFE) | Solder | 1 | SLB | Beryllium Copper | Female Socket Plug | Gold | Board Edge End Launch | Solder | Snap-On | ||||||
 Radiall USA, Inc. | Brass | Gold | Gold | Polytetrafluoroethylene (PTFE) | Solder | 1 | SLB | Beryllium Copper | Female Socket Plug | Gold | Through Hole | Solder | Snap-On | 500 | 0.3 dB | -65 ░C | 165 °C | 50 Ohms | 4 GHz |
