1812Y Series

Catalog

MULTILAYER CERAMIC CAPACITORS MLCC - SMD/SMT

...

Part	Voltage - Rated	Operating Temperature [Min]	Operating Temperature [Max]	Package / Case	Capacitance	Temperature Coefficient	Tolerance	Features	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Applications	Mounting Type	Thickness (Max) [Max]	Thickness (Max) [Max]	Voltage - Rated	Ratings
Knowles Syfer 1812Y0500222KCT	50 VDC	-55 C	125 °C	1812 (4532 Metric)	2200 pF	C0G NP0	10 %	Soft Termination	0.177 in	4.5 mm	3.2 mm	0.126 in	Boardflex Sensitive	MLCC Surface Mount	2.5 mm	0.098 in
Knowles Syfer 1812Y5000122MDT	500 V	-55 C	125 °C	1812 (4532 Metric)	1200 pF	X7R	20 %	Soft Termination	0.177 in	4.5 mm	3.2 mm	0.126 in	Boardflex Sensitive	MLCC Surface Mount	2.5 mm	0.098 in
Knowles Syfer 1812Y5K00102JXT	5 kV	-55 C	125 °C	1812 (4532 Metric)	0.001 µF	X7R	5 %	Soft Termination	0.177 in	4.5 mm	3.2 mm	0.126 in	Boardflex Sensitive	MLCC Surface Mount	2.5 mm	0.098 in	5 kV
Knowles Syfer 1812Y5000151FFT	500 V	-55 C	125 °C	1812 (4532 Metric)	150 pF	C0G NP0	1 %	Soft Termination	0.177 in	4.5 mm	3.2 mm	0.126 in	Boardflex Sensitive	MLCC Surface Mount	2.5 mm	0.098 in
Knowles Syfer 1812Y5K00270JCR	5 kV	-55 C	125 °C	1812 (4532 Metric)	27 pF	C0G NP0	5 %	Soft Termination	0.177 in	4.5 mm	3.2 mm	0.126 in	Boardflex Sensitive	MLCC Surface Mount	2.5 mm	0.098 in	5 kV
Knowles Syfer 1812Y1K00561KXT	1000 V	-55 C	125 °C	1812 (4532 Metric)	560 pF	X7R	10 %	Soft Termination	0.177 in	4.5 mm	3.2 mm	0.126 in	Boardflex Sensitive	MLCC Surface Mount	2.5 mm	0.098 in	1 kV
Knowles Syfer 1812Y0500682GCT	50 VDC	-55 C	125 °C	1812 (4532 Metric)	6800 pF	C0G NP0	2 %	Soft Termination	0.177 in	4.5 mm	3.2 mm	0.126 in	Boardflex Sensitive	MLCC Surface Mount	2.5 mm	0.098 in
Knowles Syfer 1812Y0630564JET	63 V	-55 C	125 °C	1812 (4532 Metric)	560 nF	X7R	5 %	Soft Termination	0.177 in	4.5 mm	3.2 mm	0.126 in	Automotive Boardflex Sensitive	MLCC Surface Mount	2.5 mm	0.098 in		AEC-Q200
Knowles Syfer 1812Y0500331GFT	50 VDC	-55 C	125 °C	1812 (4532 Metric)	330 pF	C0G NP0	2 %	Soft Termination	0.177 in	4.5 mm	3.2 mm	0.126 in	Boardflex Sensitive	MLCC Surface Mount	2.5 mm	0.098 in
Knowles Syfer 1812Y1K00153MXT	1000 V	-55 C	125 °C	1812 (4532 Metric)	15000 pF	X7R	20 %	Soft Termination	0.177 in	4.5 mm	3.2 mm	0.126 in	Boardflex Sensitive	MLCC Surface Mount	2.5 mm	0.098 in	1 kV
