LNJ808 Series

Catalog

LED ORANGE SS TYPE LED SMD

Part	Configuration	Height (Max) [Max]	Lens Style	Mounting Type	Current - Test	Millicandela Rating	Wavelength - Peak	Lens Size [x]	Lens Size [y]	Package / Case	Voltage - Forward (Vf) (Typ)	Size / Dimension [x]	Size / Dimension [y]
Panasonic Industrial Automation Sales LNJ808R8ERA	Standard	0.9 mm	Rectangle with Flat Top	Surface Mount	5 mA	1.1 mcd	630 nm	0.9 mm	0.8 mm	0603 (1608 Metric)	1.8 V	1.6 mm	0.8 mm
Panasonic Industrial Automation Sales LNJ808K8SRA	Standard	0.9 mm	Rectangle with Flat Top	Surface Mount	10 mA	1 mcd	610 nm	0.9 mm	0.8 mm	0603 (1608 Metric)	1.93 V	1.6 mm	0.8 mm
Panasonic Industrial Automation Sales LNJ808K87RA	Standard	0.9 mm	Rectangle with Flat Top	Surface Mount	10 mA	21 mcd	615 nm	0.9 mm	0.8 mm	0603 (1608 Metric)	1.95 V	1.6 mm	0.8 mm
