ZUW152412 Series
Manufacturer: Cosel USA, Inc.
Beta
⌘K
DC DC CONVERTER +/-12V 24V 16W
| Part | Package / Case | Mounting Type | Type | Voltage - Output 2 | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [z] | Current - Output (Max) [Max] | Current - Output (Max) [Max] | Voltage - Output 1 | Power (Watts) | Voltage - Input (Min) [Min] | Operating Temperature [Min] | Operating Temperature [Max] | Number of Outputs | Voltage - Input (Max) [Max] | Efficiency | Applications | Voltage - Isolation |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Cosel USA, Inc. | 7-DIP Module | Through Hole | Isolated Module | -12 V | 45 mm | 50 mm | 1.97 " | 1.77 in | 8.5 mm | 0.33 in | 650 mA | 650 mA | 12 V | 16 W | 18 V | -20 °C | 71 °C | 2 | 36 V | 83 % | ITE (Commercial) | 500 V |
