387-013 Series
Manufacturer: EDAC Inc.
Catalog
CONN EDGE SGL FMALE 13POS 0.156
...
| Part | Color | Number of Positions/Bay/Row [custom] | Card Thickness [Min] | Card Thickness [Min] | Card Thickness [Max] | Card Thickness [Max] | Card Type | Contact Material | Read Out | Number of Rows | Contact Type | Pitch [x] | Pitch [x] | Termination Rows | Operating Temperature [Min] | Operating Temperature [Max] | Number of Positions | Contact Finish Thickness | Contact Finish Thickness | Gender | Termination | Mounting Type | Flange Feature | Contact Finish | Material - Insulation | Flange Feature [diameter] | Flange Feature [diameter] | Flange Feature | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Black | 13 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Non Specified - Single Edge | Copper Alloy | Single | 1 | Cantilever | 0.156 in | 3.96 mm | 1 | -40 °C | 105 ░C | 13 | 10 Áin | 0.25 Ám | Female | Solder | Through Hole | 4-40 Threaded Insert Top Mount Opening | Gold | Polyester Thermoplastic | ||||
 EDAC Inc. | Black | 13 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Non Specified - Single Edge | Copper Alloy | Single | 1 | Cantilever | 0.156 in | 3.96 mm | 1 | -40 °C | 105 ░C | 13 | 10 Áin | 0.25 Ám | Female | Wire Wrap | Through Hole | Top Mount Opening Unthreaded | Gold | Polyester Thermoplastic | 0.156 in | 3.96 mm | ||
 EDAC Inc. | Black | 13 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Non Specified - Single Edge | Copper Alloy | Single | 1 | Cantilever | 0.156 in | 3.96 mm | 1 | -40 °C | 105 ░C | 13 | 10 Áin | 0.25 Ám | Female | Wire Wrap | Through Hole Right Angle | 4-40 Flush Mount Threaded Insert Top Opening | Gold | Polyester Thermoplastic | ||||
 EDAC Inc. | Black | 13 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Non Specified - Single Edge | Copper Alloy | Single | 1 | Cantilever | 0.156 in | 3.96 mm | 1 | -40 °C | 105 ░C | 13 | 10 Áin | 0.25 Ám | Female | Wire Wrap | Through Hole | Side Mount Opening Unthreaded | Gold | Polyester Thermoplastic | 3.25 mm | 0.128 in | ||
 EDAC Inc. | Black | 13 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Non Specified - Single Edge | Copper Alloy | Single | 1 | Cantilever | 0.156 in | 3.96 mm | 1 | -40 °C | 105 ░C | 13 | 10 Áin | 0.25 Ám | Female | Wire Wrap | Through Hole | 4-40 Flush Mount Threaded Insert Top Opening | Gold | Polyester Thermoplastic | ||||
 EDAC Inc. | Black | 13 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Non Specified - Single Edge | Copper Alloy | Single | 1 | Cantilever | 0.156 in | 3.96 mm | 1 | -40 °C | 105 ░C | 13 | 10 Áin | 0.25 Ám | Female | Wire Wrap | Through Hole | Floating Bobbin Flush Mount | Gold | Polyester Thermoplastic | 0.116 in | 2.95 mm | ||
 EDAC Inc. | Black | 13 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Non Specified - Single Edge | Copper Alloy | Single | 1 | Cantilever | 0.156 in | 3.96 mm | 1 | -40 °C | 105 ░C | 13 | 10 Áin | 0.25 Ám | Female | Solder | Through Hole | Gold | Polyester Thermoplastic | 3.25 mm | 0.128 in | |||
 EDAC Inc. | Black | 13 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Non Specified - Single Edge | Copper Alloy | Single | 1 | Cantilever | 0.156 in | 3.96 mm | 1 | -40 °C | 105 ░C | 13 | 10 Áin | 0.25 Ám | Female | Solder | Through Hole | 4-40 Threaded Insert Top Mount Opening | Gold | Polyester Thermoplastic | ||||
 EDAC Inc. | Black | 13 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Non Specified - Single Edge | Copper Alloy | Single | 1 | Cantilever | 0.156 in | 3.96 mm | 1 | -40 °C | 105 ░C | 13 | 10 Áin | 0.25 Ám | Female | Solder | Through Hole | Side Mount Opening Unthreaded | Gold | Polyester Thermoplastic | 3.25 mm | 0.128 in | ||
 EDAC Inc. | Black | 13 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Non Specified - Single Edge | Copper Alloy | Single | 1 | Cantilever | 0.156 in | 3.96 mm | 1 | -40 °C | 105 ░C | 13 | 10 Áin | 0.25 Ám | Female | Wire Wrap | Through Hole Right Angle | Flush Mount Top Opening Unthreaded | Gold | Polyester Thermoplastic | 0.128 " | 3.25 mm |
