T18SN6 Series
Manufacturer: BANNER ENGINEERING
Beta
⌘K
PHOTO SEN 100MM COMP NPN
| Part | Ingress Protection | Sensing Distance | Sensing Distance | Sensing Method | Output Configuration | Connection Method | Light Source | Operating Temperature [Max] | Operating Temperature [Min] | Voltage - Supply [Min] | Voltage - Supply [Max] | Response Time | Adjustment Type | Cable Length | Cable Length |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 BANNER ENGINEERING | IP69K NEMA 6P | 10 cm | 3.937 in | Background Suppression | NPN - Dark-ON/Light-ON | Connector | Infrared (880nm) | 70 °C | -40 C | 10 VDC | 30 VDC | 3 ms | |||
 BANNER ENGINEERING | IEC IEC IP67 IEC IP69K IP67 IP69K NEMA 6P | 2 m | 78.74 in | Retroreflective NonPolarized | Connector | Infrared (950nm) | 70 °C | -40 C | 10 VDC | 30 VDC | 3 ms | Adjustable Potentiometer | |||
BANNER ENGINEERING | IEC IEC IP67 IEC IP69K IP67 IP69K NEMA 6P | 2 m | 78.74 in | Retroreflective NonPolarized | Cable | Infrared (950nm) | 70 °C | -40 C | 10 VDC | 30 VDC | 3 ms | Adjustable Potentiometer | 78.74 " | 2 m | |
 BANNER ENGINEERING | IEC IEC IP67 IEC IP69K IP67 IP69K NEMA 6P | 2000 cm | 787.402 in | Through-Beam | NPN - Dark-ON/Light-ON | Connector | Infrared (950nm) | 70 °C | -40 C | 10 VDC | 30 VDC | 3 ms | |||
 BANNER ENGINEERING | IP69K NEMA 6P | 5 cm | 1.969 in | Background Suppression | NPN - Dark-ON/Light-ON | Connector | Infrared (880nm) | 70 °C | -40 C | 10 VDC | 30 VDC | 3 ms | |||
 BANNER ENGINEERING | IP69K NEMA 6P | 2 m | 78.74 in | Polarized Retroreflective | NPN - Dark-ON/Light-ON | Connector | Red (680nm) | 70 °C | -40 C | 10 VDC | 30 VDC | 3 ms | |||
 BANNER ENGINEERING | IEC IP67 IP69K NEMA 6P | 2 m | 78.74 in | Polarized Retroreflective | Cable | Red (680nm) | 70 °C | -40 C | 3 ms | 78.74 " | 2 m | ||||
 BANNER ENGINEERING | IEC IEC IP67 IEC IP69K IP67 IP69K NEMA 6P | 50 cm | 19.685 in | Diffuse | NPN - Dark-ON/Light-ON | Connector | Infrared (880nm) | 70 °C | -40 C | 10 VDC | 30 VDC | 3 ms | Adjustable Potentiometer | ||
 BANNER ENGINEERING | IEC IEC IP67 IEC IP69K IP67 IP69K NEMA 6P | 2000 cm | 787.402 in | Through-Beam | NPN - Dark-ON/Light-ON | Cable | Infrared (950nm) | 70 °C | -40 C | 10 VDC | 30 VDC | 3 ms | 78.74 " | 2 m | |
 BANNER ENGINEERING | IEC IEC IP67 IEC IP69K IP67 IP69K NEMA 6P | 50 cm | 19.685 in | Diffuse | NPN - Dark-ON/Light-ON | Connector | Infrared (880nm) | 70 °C | -40 C | 10 VDC | 30 VDC | 3 ms | Adjustable Potentiometer |
