MSS40 Series

Catalog

RF DIODE SCHOTTKY 3V 100MW E25

Part	Voltage - Peak Reverse (Max) [Max]	Resistance @ If, F	Diode Type	Power Dissipation (Max) [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Package / Case	Current - Max [Max]	Capacitance @ Vr, F	Supplier Device Package
MACOM Technology Solutions MSS40-141-E25	3 V	10 Ohm	Schottky - Single	100 mW	150 °C	-65 ░C	E25	50 mA	0.22 pF	E25
MACOM Technology Solutions MSS40-448-E45R	3 V	7 Ohm	Schottky - 1 Bridge	100 mW	150 °C	-65 ░C	E45	50 mA	0.3 pF	E45
MACOM Technology Solutions MSS40-448-B42	3 V	17 Ohm	Schottky - Ring	100 mW	150 °C	-65 ░C	B42	50 mA	0.15 pF	B42
