CP24L-A2BE Series
Manufacturer: MEAN WELL USA Inc.
Beta
⌘K
22MM/BL/LIGHT24V/MAINTAINED/1NO
| Part | Electrical Life | Mechanical Life | Actuator Type | Termination Style | Color - Actuator/Cap | Current Rating (Amps) | Circuit | Operating Temperature [Max] | Operating Temperature [Min] | Switch Function | Mounting Type | Voltage Rating - DC | Voltage Rating - AC | Illumination Type, Color | Type | Ingress Protection | Panel Cutout Dimensions [diameter] | Illumination Voltage (Nominal) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 MEAN WELL USA Inc. | 100000 Cycles | 250000 Cycles | Button Round | Spring Terminal | Blue | 2.5 A 8 A | SPST-NO | 55 °C | -25 °C | Off-On | Panel Mount Front | 30 V | 120 V | Blue LED | Illuminated Standard | IP66 - Dust Tight Water Resistant | 22.3 mm | 24 VAC/DC |
