45002 Series
Manufacturer: ALPHA WIRE
Beta
⌘K
MULTICONDUCTOR CABLE, UNSHIELDED, 2 CONDUCTOR, 22 AWG, 0.35 MM², 100 FT, 30.5 M
| Part | Length [x] | Length [x] | Wire Gauge | Features | Number of Conductors | Conductor Insulation | Voltage | Operating Temperature [Min] | Operating Temperature [Max] | Jacket Color | Ratings | Conductor Strand [custom] | Conductor Strand [custom] | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness | Jacket (Insulation) Material | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Conductor Material | Cable Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 ALPHA WIRE | 30.5 m | 100 ft | 22 AWG | Biological Compatibility Rip Cord | 2 | Thermoplastic Elastomer (TPE) | 300 V | -50 °C | 125 °C | Black | ISO 10993 | 7 | 30 AWG | 1.143 mm | 0.045 in | Thermoplastic Elastomer (TPE) | 5.54 mm | 0.218 in | Copper Tinned | Multi-Conductor |
