DC0011/05 Series

Catalog

THERM PAD 17.45MMX14.27MM W/ADH

Part	Shelf Life	Type	Outline [x]	Outline [y]	Color	Thermal Conductivity	Adhesive	Usage	Shape	Thickness	Thickness	Shelf Life Start	Thickness	Material	Backing, Carrier
t-Global Technology DC0011/05-TG-A373F-0.25-2A	12 Months	Die-Cut Pad Sheet	17.45 mm	14.27 mm	Yellow	1.4 W/m-K	Adhesive - Both Sides	TO-220	Rectangular	0.01 in	10 mils
t-Global Technology DC0011/05-TG-A486G-0.3-2A	12 Months	Die-Cut Pad Sheet	17.45 mm	14.27 mm	Gray	6 W/m-K	Adhesive - Both Sides	TO-220	Rectangular		0.305 mm	Date of Purchase	0.012 in
t-Global Technology DC0011/05-TI900-0.12-0	36 Months	Die-Cut Pad Sheet	17.45 mm	14.27 mm	White	1.8 W/m-K		TO-220	Rectangular		5 mils		0.005 in	Silicone	Viscose
t-Global Technology DC0011/05-TG-AH482-2.0-0	24 Months	Die-Cut Pad Sheet	17.45 mm	14.27 mm	Red	2.2 W/m-K		TO-220	Rectangular		2 mm		0.079 in
t-Global Technology DC0011/05-TG-A482K-0.1-0	24 Months	Die-Cut Pad Sheet	17.45 mm	14.27 mm	Red	2.3 W/m-K		TO-220	Rectangular		0.1 mm	Date of Purchase	0.0039 in	Silicone
t-Global Technology DC0011/05-TI900-0.12-2A	24 Months	Die-Cut Pad Sheet	17.45 mm	14.27 mm	White	1.8 W/m-K	Adhesive - Both Sides	TO-220	Rectangular		5 mils		0.005 in	Silicone	Viscose
