PXP6012 Series
Manufacturer: BULGIN LIMITED
Beta
⌘K
CIRCULAR CONNECTOR, BUCCANEER 6000 SERIES, PANEL MOUNT RECEPTACLE, 3 CONTACTS, SCREW SOCKET
| Part | Current Rating (Amps) | Mounting Feature | Mounting Type | Shell Material | Fastening Type | Orientation | Number of Positions | Material Flammability Rating | Ingress Protection | Features | Connector Type | Color | Operating Temperature [Max] | Operating Temperature [Min] | Contact Finish - Mating | Primary Material | Shielding | Voltage Rating | Termination | Contact Material | Type | Contact Shape | Housing Color | Note | Contact Type | Includes |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 BULGIN LIMITED | 11 A 16 A | Bulkhead - Rear Side Nut | Panel Mount | Halogen Free Polycarbonate/Polybutylene Terephthalate (PBT) | Push-Twist | Keyed | 3 | UL94 V-0 | IP66 IP68 IP69K | UV Resistant | Plug Female Sockets | Gray | 120 °C | -40 C | Nickel | Plastic | Unshielded | 277 VAC | Screw | Brass | ||||||
 BULGIN LIMITED | 11 A 16 A | Bulkhead - Rear Side Nut | Panel Mount | Halogen Free Polycarbonate/Polybutylene Terephthalate (PBT) | Push-Twist | Keyed | 2 | UL94 V-0 | IP66 IP68 IP69K | UV Resistant | Plug Male Pins | Gray | 120 °C | -40 C | Nickel | Plastic | Unshielded | 277 VAC | Screw | Brass | ||||||
 BULGIN LIMITED | 11 A 16 A | Bulkhead - Rear Side Nut | Panel Mount | Halogen Free Polycarbonate/Polybutylene Terephthalate (PBT) | Push-Twist | Keyed | 3 | UL94 V-0 | IP66 IP68 IP69K | UV Resistant | Plug Male Pins | Gray | 120 °C | -40 C | Nickel | Plastic | Unshielded | 277 VAC | Screw | Brass | ||||||
 BULGIN LIMITED | Bulkhead - Rear Side Nut | Panel Mount | Halogen Free Polycarbonate/Polybutylene Terephthalate (PBT) | Push-Twist | Keyed | 16 | UL94 V-0 | IP66 IP68 IP69K | Receptacle Housing | 120 °C | -40 C | Plastic | Unshielded | For Male Pins | Circular | Gray | Contacts Not Included | Crimp and Solder Cup | 1 Nut 1 Washer 3 pcs - 1 Connector | |||||||
 BULGIN LIMITED | 11 A 16 A | Bulkhead - Rear Side Nut | Panel Mount | Halogen Free Polycarbonate/Polybutylene Terephthalate (PBT) | Push-Twist | Keyed | 2 | UL94 V-0 | IP66 IP68 IP69K | UV Resistant | Plug Female Sockets | Gray | 120 °C | -40 C | Nickel | Plastic | Unshielded | 277 VAC | Screw | Brass | ||||||
 BULGIN LIMITED | Bulkhead - Rear Side Nut | Panel Mount | Halogen Free Polycarbonate/Polybutylene Terephthalate (PBT) | Push-Twist | Keyed | 22 | UL94 V-0 | IP66 IP68 IP69K | Receptacle Housing | 120 °C | -40 C | Plastic | Unshielded | For Male Pins | Circular | Gray | Contacts Not Included | Crimp and Solder Cup | 1 Nut 1 Washer 3 pcs - 1 Connector |
