5199/60C Series
Manufacturer: ALPHA WIRE
Beta
⌘K
CABLE 60 COND 22AWG BLACK 1000'
| Part | Shield Material | Shield Coverage | Features | Conductor Insulation | Conductor Strand [custom] | Conductor Strand [custom] | Voltage | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness | Usage | Jacket (Insulation) Material | Number of Conductors | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Cable Type | Ratings | Length | Length | Jacket Color | Operating Temperature [Min] | Operating Temperature [Max] | Wire Gauge | Shield Type | Conductor Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 ALPHA WIRE | Aluminum | 100 % | Biological Compatibility Drain Wire Rip Cord | Poly-Vinyl Chloride (PVC) | 30 AWG | 7 | 300 VDC | 0.813 mm | 0.032 in | Communication Control | Poly-Vinyl Chloride (PVC) | 60 | 0.522 " | 13.26 mm | Multi-Conductor | ISO 10993 | 304.8 m | 1000 ft | Black | -35 °C | 105 ░C | 22 AWG | Foil | Copper Tinned |
 ALPHA WIRE | Aluminum | 100 % | Biological Compatibility Drain Wire Rip Cord | Poly-Vinyl Chloride (PVC) | 30 AWG | 7 | 300 VDC | 0.813 mm | 0.032 in | Communication Control | Poly-Vinyl Chloride (PVC) | 60 | 0.522 " | 13.26 mm | Multi-Conductor | ISO 10993 | 152.4 m | 500 ft | Slate | -35 °C | 105 ░C | 22 AWG | Foil | Copper Tinned |
