781801 Series

Catalog

HOOK-UP SOLID 18AWG RED 100'

Part	Jacket (Insulation) Material	Wire Gauge	Conductor Strand	Conductor Material	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Length [x]	Length [x]	Cable Type	Voltage	Ratings	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Jacket Color	Operating Temperature [Min]	Operating Temperature [Max]	Length	Length
ALPHA WIRE 781801 RD005	Poly-Vinyl Chloride (PVC)	18 AWG	Solid	Copper Tinned	0.81 mm	0.032 in	30.5 m	100 ft	Hook-Up	600 V	UL Style 1015/1230	2.64 mm	0.104 in	Red	-20 C	105 ░C
ALPHA WIRE 781801 VI005	Poly-Vinyl Chloride (PVC)	18 AWG	Solid	Copper Tinned	0.81 mm	0.032 in	30.5 m	100 ft	Hook-Up	600 V	UL Style 1015/1230	2.64 mm	0.104 in	Violet	-20 C	105 ░C
ALPHA WIRE 781801 BK005	Poly-Vinyl Chloride (PVC)	18 AWG	Solid	Copper Tinned	0.81 mm	0.032 in	30.5 m	100 ft	Hook-Up	600 V	UL Style 1015/1230	2.64 mm	0.104 in	Black	-20 C	105 ░C
ALPHA WIRE 781801 BL001	Poly-Vinyl Chloride (PVC)	18 AWG	Solid	Copper Tinned	0.81 mm	0.032 in			Hook-Up	600 V	UL Style 1015/1230	2.64 mm	0.104 in	Blue	-20 C	105 ░C	1000 ft	304.8 m
ALPHA WIRE 781801 BL013	Poly-Vinyl Chloride (PVC)	18 AWG	Solid	Copper Tinned	0.81 mm	0.032 in			Hook-Up	600 V	UL Style 1015/1230	2.64 mm	0.104 in	Blue	-20 C	105 ░C
ALPHA WIRE 781801 GR001	Poly-Vinyl Chloride (PVC)	18 AWG	Solid	Copper Tinned	0.81 mm	0.032 in			Hook-Up	600 V	UL Style 1015/1230	2.64 mm	0.104 in	Green	-20 C	105 ░C	1000 ft	304.8 m
ALPHA WIRE 781801 BL005	Poly-Vinyl Chloride (PVC)	18 AWG	Solid	Copper Tinned	0.81 mm	0.032 in	30.5 m	100 ft	Hook-Up	600 V	UL Style 1015/1230	2.64 mm	0.104 in	Blue	-20 C	105 ░C
ALPHA WIRE 781801 SL001	Poly-Vinyl Chloride (PVC)	18 AWG	Solid	Copper Tinned	0.81 mm	0.032 in			Hook-Up	600 V	UL Style 1015/1230	2.64 mm	0.104 in	Slate	-20 C	105 ░C	1000 ft	304.8 m
ALPHA WIRE 781801 GR005	Poly-Vinyl Chloride (PVC)	18 AWG	Solid	Copper Tinned	0.81 mm	0.032 in	30.5 m	100 ft	Hook-Up	600 V	UL Style 1015/1230	2.64 mm	0.104 in	Green	-20 C	105 ░C
ALPHA WIRE 781801 BK001	Poly-Vinyl Chloride (PVC)	18 AWG	Solid	Copper Tinned	0.81 mm	0.032 in			Hook-Up	600 V	UL Style 1015/1230	2.64 mm	0.104 in	Black	-20 C	105 ░C	1000 ft	304.8 m
