337-043 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 43POS 0.156
| Part | Material - Insulation | Termination Rows | Operating Temperature [Min] | Operating Temperature [Max] | Gender | Card Thickness [Max] | Card Thickness [Min] | Number of Positions | Card Type | Pitch | Pitch | Contact Material | Contact Finish Thickness | Contact Finish Thickness | Termination | Color | Mounting Type | Contact Type | Contact Finish | Number of Rows | Number of Positions/Bay/Row | Read Out | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 1 | -40 C | 105 ░C | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 43 | Non Specified - Single Edge | 3.96 mm | 0.156 in | Copper Alloy | 0.25 Ám | 10 Áin | Wire Wrap | Green | Through Hole | Cantilever | Gold | 1 | 43 | Single | 4-40 Threaded Insert Top Mount Opening | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | -40 C | 105 ░C | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 43 | Non Specified - Single Edge | 3.96 mm | 0.156 in | Copper Alloy | 0.25 Ám | 10 Áin | Wire Wrap | Green | Through Hole | Cantilever | Gold | 1 | 43 | Single | 4-40 Flush Mount Threaded Insert Top Opening | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | -40 C | 105 ░C | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 43 | Non Specified - Single Edge | 3.96 mm | 0.156 in | Copper Alloy | 0.25 Ám | 10 Áin | Wire Wrap | Green | Through Hole | Cantilever | Gold | 1 | 43 | Single | 4-40 Threaded Insert Top Mount Opening | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | -40 C | 105 ░C | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 43 | Non Specified - Single Edge | 3.96 mm | 0.156 in | Copper Alloy | 0.25 Ám | 10 Áin | Wire Wrap | Green | Through Hole | Cantilever | Gold | 1 | 43 | Single | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm |
 EDAC Inc. | Polyester Thermoplastic | 1 | -40 C | 105 ░C | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 43 | Non Specified - Single Edge | 3.96 mm | 0.156 in | Copper Alloy | 0.25 Ám | 10 Áin | Solder | Green | Through Hole | Cantilever | Gold | 1 | 43 | Single | 0.128 " | 3.25 mm | |
 EDAC Inc. | Polyester Thermoplastic | 1 | -40 C | 105 ░C | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 43 | Non Specified - Single Edge | 3.96 mm | 0.156 in | Copper Alloy | 0.25 Ám | 10 Áin | Wire Wrap | Green | Through Hole | Cantilever | Gold | 1 | 43 | Single | 4-40 Threaded Insert Top Mount Opening | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | -40 C | 105 ░C | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 43 | Non Specified - Single Edge | 3.96 mm | 0.156 in | Copper Alloy | 0.25 Ám | 10 Áin | Wire Wrap | Green | Through Hole | Cantilever | Gold | 1 | 43 | Single | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm |
 EDAC Inc. | Polyester Thermoplastic | 1 | -40 C | 105 ░C | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 43 | Non Specified - Single Edge | 3.96 mm | 0.156 in | Copper Alloy | 0.25 Ám | 10 Áin | Wire Wrap | Green | Through Hole | Cantilever | Gold | 1 | 43 | Single | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm |
 EDAC Inc. | Polyester Thermoplastic | 1 | -40 C | 105 ░C | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 43 | Non Specified - Single Edge | 3.96 mm | 0.156 in | Copper Alloy | 0.25 Ám | 10 Áin | Solder | Green | Through Hole | Cantilever | Gold | 1 | 43 | Single | Flush Mount M3 Threaded Insert Top Opening | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | -40 C | 105 ░C | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 43 | Non Specified - Single Edge | 3.96 mm | 0.156 in | Copper Alloy | 0.25 Ám | 10 Áin | Solder | Green | Through Hole | Cantilever | Gold | 1 | 43 | Single | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm |
