26 Series

Catalog

FIXED IND 12UH 2.42A 68MOHM SMD

Part	Frequency - Self Resonant	Operating Temperature [Max]	Operating Temperature [Min]	Package / Case	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Shielding	DC Resistance (DCR) [Max]	Current Rating (Amps)	Type	Mounting Type	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Inductance	Inductance Frequency - Test	DC Resistance (DCR)
Murata Electronics 26120C	24 MHz	85 °C	-40 C	Nonstandard	0.228 "	5.8 mm	Unshielded	68 mOhm	2.42 A	Wirewound	Surface Mount	0.354 in	9 mm	0.394 in	10 mm	12 µH	1 kHz
Murata Electronics 26101C	6.56 MHz	85 °C	-40 C	Nonstandard	0.228 "	5.8 mm	Unshielded	350 mOhm	970 mA	Wirewound	Surface Mount	0.354 in	9 mm	0.394 in	10 mm	100 µH	1 kHz
Murata Electronics 26220C	16.9 MHz	85 °C	-40 C	Nonstandard	0.228 "	5.8 mm	Unshielded		1.95 A	Wirewound	Surface Mount	0.354 in	9 mm	0.394 in	10 mm	22 µH	1 kHz	100 mOhm
Murata Electronics 26100C	24.8 MHz	85 °C	-40 C	Nonstandard	0.228 "	5.8 mm	Unshielded		2.6 A	Wirewound	Surface Mount	0.354 in	9 mm	0.394 in	10 mm	10 µH	1 kHz
Murata Electronics 263R3C	53 MHz	85 °C	-40 C	Nonstandard	0.228 "	5.8 mm	Unshielded	35 mOhm	4.4 A	Wirewound	Surface Mount	0.354 in	9 mm	0.394 in	10 mm	3.3 µH	1 kHz
Murata Electronics 26180C	19 MHz	85 °C	-40 C	Nonstandard	0.228 "	5.8 mm	Unshielded	87 mOhm	2.1 A	Wirewound	Surface Mount	0.354 in	9 mm	0.394 in	10 mm	18 µH	1 kHz
Murata Electronics 264R7C	37 MHz	85 °C	-40 C	Nonstandard	0.228 "	5.8 mm	Unshielded	45 mOhm	3.6 A	Wirewound	Surface Mount	0.354 in	9 mm	0.394 in	10 mm	4.7 ÁH	1 kHz
Murata Electronics 26151C	5.2 MHz	85 °C	-40 C	Nonstandard	0.228 "	5.8 mm	Unshielded		780 mA	Wirewound	Surface Mount	0.354 in	9 mm	0.394 in	10 mm	150 µH	1 kHz	470 mOhm
Murata Electronics 26150C	20.2 MHz	85 °C	-40 C	Nonstandard	0.228 "	5.8 mm	Unshielded	90 mOhm	2.27 A	Wirewound	Surface Mount	0.354 in	9 mm	0.394 in	10 mm	15 µH	1 kHz
Murata Electronics 26680C	8.37 MHz	85 °C	-40 C	Nonstandard	0.228 "	5.8 mm	Unshielded	220 mOhm	1.11 A	Wirewound	Surface Mount	0.354 in	9 mm	0.394 in	10 mm	68 µH	1 kHz
