887-074 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 74POS 0.156
| Part | Termination Rows [custom] | Material - Insulation | Mounting Type | Contact Finish Thickness | Contact Finish Thickness | Operating Temperature [Max] | Operating Temperature [Min] | Pitch | Pitch | Contact Type | Read Out | Contact Finish | Card Type | Number of Positions | Contact Material | Flange Feature | Number of Rows [custom] | Number of Positions/Bay/Row | Color | Card Thickness [Max] | Card Thickness [Min] | Gender | Termination | Flange Feature [diameter] | Flange Feature [diameter] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Right Angle Through Hole | 0.25 Ám | 10 Áin | 125 °C | -40 C | 3.96 mm | 0.156 in | Cantilever | Dual | Gold | Non Specified - Dual Edge | 74 | Copper Alloy | 4-40 Flush Mount Threaded Insert Top Opening | 2 | 37 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Solder | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Through Hole | 0.25 Ám | 10 Áin | 125 °C | -40 C | 3.96 mm | 0.156 in | Cantilever | Dual | Gold | Non Specified - Dual Edge | 74 | Copper Alloy | Flush Mount Side Opening Unthreaded | 2 | 37 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Solder | 0.128 " | 3.25 mm | |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Through Hole | 0.25 Ám | 10 Áin | 125 °C | -40 C | 3.96 mm | 0.156 in | Cantilever | Dual | Gold | Non Specified - Dual Edge | 74 | Copper Alloy | Flush Mount M3 Threaded Insert Top Opening | 2 | 37 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Solder | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Through Hole | 0.25 Ám | 10 Áin | 125 °C | -40 C | 3.96 mm | 0.156 in | Cantilever | Dual | Gold | Non Specified - Dual Edge | 74 | Copper Alloy | M3 Threaded Insert Top Mount Opening | 2 | 37 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Solder | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Through Hole | 0.25 Ám | 10 Áin | 125 °C | -40 C | 3.96 mm | 0.156 in | Cantilever | Dual | Gold | Non Specified - Dual Edge | 74 | Copper Alloy | 4-40 Flush Mount Threaded Insert Top Opening | 2 | 37 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Wire Wrap | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Through Hole | 0.25 Ám | 10 Áin | 125 °C | -40 C | 3.96 mm | 0.156 in | Cantilever | Dual | Gold | Non Specified - Dual Edge | 74 | Copper Alloy | Side Mount Opening Unthreaded | 2 | 37 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Solder | 0.128 " | 3.25 mm | |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Through Hole | 0.25 Ám | 10 Áin | 125 °C | -40 C | 3.96 mm | 0.156 in | Cantilever | Dual | Gold | Non Specified - Dual Edge | 74 | Copper Alloy | Flush Mount Side Opening Unthreaded | 2 | 37 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Solder Eyelet(s) | 0.128 " | 3.25 mm | |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Through Hole | 0.25 Ám | 10 Áin | 125 °C | -40 C | 3.96 mm | 0.156 in | Cantilever | Dual | Gold | Non Specified - Dual Edge | 74 | Copper Alloy | Flush Mount Top Opening Unthreaded | 2 | 37 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Solder | 0.128 " | 3.25 mm | |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Board Edge Straddle Mount | 0.25 Ám | 10 Áin | 125 °C | -40 C | 3.96 mm | 0.156 in | Cantilever | Dual | Gold | Non Specified - Dual Edge | 74 | Copper Alloy | 2 | 37 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Solder | Card Extender | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Through Hole | 0.25 Ám | 10 Áin | 125 °C | -40 C | 3.96 mm | 0.156 in | Cantilever | Dual | Gold | Non Specified - Dual Edge | 74 | Copper Alloy | 2 | 37 | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Solder | 0.156 " | 3.96 mm |
