TS3A44159 Series

0.4-Ω on-state resistance, 3.3-V, 2:1 (SPDT), 4-channel analog switch

Catalog

0.4-Ω on-state resistance, 3.3-V, 2:1 (SPDT), 4-channel analog switch

Part	Crosstalk	Switch Circuit	Channel Capacitance (CS(off), CD(off)) [custom]	Channel Capacitance (CS(off), CD(off)) [custom]	Supplier Device Package	Supplier Device Package [y]	Supplier Device Package [x]	Current - Leakage (IS(off)) (Max)	Channel-to-Channel Matching (ΔRon)	Switch Time (Ton, Toff) (Max) [custom]	Switch Time (Ton, Toff) (Max) [custom]	-3db Bandwidth	Operating Temperature [Max]	Operating Temperature [Min]	Mounting Type	Multiplexer/Demultiplexer Circuit	Charge Injection	Number of Circuits	Package / Case	Voltage - Supply, Single (V+) [Max]	Voltage - Supply, Single (V+) [Min]	On-State Resistance (Max) [Max]	Operating Temperature	Package / Case [y]	Package / Case [y]
Texas Instruments TS3A44159RSVR	-73 dB	SPDT	50 pF	50 pF	16-UQFN	1.8	2.6	20 nA	50 mOhm	23 ns	32 ns	35 MHz	85 C	-40 ¯C	Surface Mount	2:1	139 pC	4	16-UFQFN	4.3 V	1.65 V	450 mOhm
Texas Instruments TS3A44159RGTR	-73 dB	SPDT	50 pF	50 pF	16-VQFN 3x3			20 nA	50 mOhm	23 ns	32 ns	35 MHz	85 C	-40 ¯C	Surface Mount	2:1	139 pC	4	16-VFQFN Exposed Pad	4.3 V	1.65 V	450 mOhm
Texas Instruments TS3A44159TD1	-73 dB	SPDT	50 pF	50 pF	Die			20 nA	50 mOhm	23 ns	32 ns	35 MHz			Surface Mount	2:1	139 pC	4	Die	4.3 V	1.65 V	450 mOhm	25 °C
Texas Instruments TS3A44159RSVRG4	-73 dB	SPDT	50 pF	50 pF	16-UQFN	1.8	2.6	20 nA	50 mOhm	23 ns	32 ns	35 MHz	85 C	-40 ¯C	Surface Mount	2:1	139 pC	4	16-UFQFN	4.3 V	1.65 V	450 mOhm
Texas Instruments TS3A44159PWRG4	-73 dB	SPDT	50 pF	50 pF	16-TSSOP			20 nA	50 mOhm	23 ns	32 ns	35 MHz	85 C	-40 ¯C	Surface Mount	2:1	139 pC	4	16-TSSOP	4.3 V	1.65 V	450 mOhm		4.4 mm	0.173 in
Texas Instruments TS3A44159PWR	-73 dB	SPDT	50 pF	50 pF	16-TSSOP			20 nA	50 mOhm	23 ns	32 ns	35 MHz	85 C	-40 ¯C	Surface Mount	2:1	139 pC	4	16-TSSOP	4.3 V	1.65 V	450 mOhm		4.4 mm	0.173 in
Texas Instruments TS3A44159RGTRG4	-73 dB	SPDT	50 pF	50 pF	16-VQFN 3x3			20 nA	50 mOhm	23 ns	32 ns	35 MHz	85 C	-40 ¯C	Surface Mount	2:1	139 pC	4	16-VFQFN Exposed Pad	4.3 V	1.65 V	450 mOhm
Texas Instruments TS3A44159TD2	-73 dB	SPDT	50 pF	50 pF	Die			20 nA	50 mOhm	23 ns	32 ns	35 MHz			Surface Mount	2:1	139 pC	4	Die	4.3 V	1.65 V	450 mOhm	25 °C

Catalog

0.4-Ω on-state resistance, 3.3-V, 2:1 (SPDT), 4-channel analog switch

Description

The TS3A44159 is a bidirectional 4-channel single-pole double-throw (SPDT) analog switch with two control inputs, which is designed to operate from 1.65 V to 4.3 V. This device is also known as a 2 channel double-pole double-throw (DPDT) configuration. It offers low ON-state resistance and excellent ON-state resistance matching with the break-before-make feature that prevents signal distortion during the transferring of a signal from one channel to another. The device has an excellent total harmonic distortion (THD) performance and consumes very low power. These features make this device suitable for portable audio applications The TS3A44159 is a bidirectional 4-channel single-pole double-throw (SPDT) analog switch with two control inputs, which is designed to operate from 1.65 V to 4.3 V. This device is also known as a 2 channel double-pole double-throw (DPDT) configuration. It offers low ON-state resistance and excellent ON-state resistance matching with the break-before-make feature that prevents signal distortion during the transferring of a signal from one channel to another. The device has an excellent total harmonic distortion (THD) performance and consumes very low power. These features make this device suitable for portable audio applications
