P18 Series

Catalog

CONN SPADE TERM 18-22AWG #6

Part	Termination	Contact Finish	Contact Material	Terminal Type	Mounting Type	Wire Gauge [Max]	Wire Gauge [Min]	Width - Outer Edges [y]	Width - Outer Edges [y]	Features	Length - Overall [x]	Length - Overall [x]	Tongue Inside Opening [x]	Tongue Inside Opening [x]	Stud/Tab Size	Insulation	Stud/Tab Size	Width - Outer Edges	Thickness	Thickness	Length - Overall	Length - Overall
Panduit Corp P18-6LF-C	Crimp	Tin	Copper	Snap Spring	Free Hanging (In-Line)	22 AWG	17.5 AWG	0.27 in	6.86 mm	Brazed Seam	17.27 mm	0.68 in	3.81 mm	0.15 in	6 Stud	Non-Insulated
Panduit Corp P18-8R-C	Crimp	Tin	Copper	Circular	Free Hanging (In-Line)	22 AWG	17.5 AWG	0.31 in		Brazed Seam Serrated Termination						Non-Insulated	8 Stud	7.87 mm	0.03 in	0.76 mm	18.03 mm	0.71 "
Panduit Corp P18-6RHT6-M	Crimp	Nickel	Copper	Circular	Free Hanging (In-Line)	22 AWG	16 AWG	0.25 "	6.35 mm	Brazed Seam Serrated Termination					6 Stud	Non-Insulated			0.03 in	0.76 mm
Panduit Corp P18-6RHT6-C	Crimp	Nickel	Copper	Circular	Free Hanging (In-Line)	22 AWG	17.5 AWG	0.25 "	6.35 mm	Brazed Seam Serrated Termination					6 Stud	Non-Insulated			0.03 in	0.76 mm
Panduit Corp P18-8RHT6-C	Crimp	Nickel	Copper	Circular	Free Hanging (In-Line)	22 AWG	17.5 AWG	0.31 in		Brazed Seam Serrated Termination						Non-Insulated	8 Stud	7.87 mm	0.03 in	0.76 mm	18.03 mm	0.71 "
Panduit Corp P18-6F-M	Crimp	Tin	Copper	Standard	Free Hanging (In-Line)	22 AWG	16 AWG			Brazed Seam	16 mm	0.63 "	3.81 mm	0.15 in	6 Stud	Non-Insulated
Panduit Corp P18-8F-C	Crimp	Tin	Copper	Standard	Free Hanging (In-Line)	22 AWG	16 AWG	0.32 in	8.13 mm	Brazed Seam		0.69 in	4.32 mm	0.17 in		Non-Insulated	8 Stud				17.53 mm
Panduit Corp P18-6F-C	Crimp	Tin	Copper	Standard	Free Hanging (In-Line)	22 AWG	16 AWG			Brazed Seam	16 mm	0.63 "	3.81 mm	0.15 in	6 Stud	Non-Insulated
Panduit Corp P18-10RHT6-M	Crimp	Nickel	Copper	Circular	Free Hanging (In-Line)	22 AWG	17.5 AWG	0.31 in		Brazed Seam Serrated Termination					10 Stud	Non-Insulated		7.87 mm	0.03 in	0.76 mm	18.03 mm	0.71 "
Panduit Corp P18-8FF-M	Crimp	Tin	Copper	Flanged	Free Hanging (In-Line)	22 AWG	17.5 AWG	0.31 in		Brazed Seam Serrated Termination			4.32 mm	0.17 in		Non-Insulated	8 Stud	7.87 mm			18.29 mm	0.72 "
