634-062 Series
Manufacturer: EDAC Inc.
Beta
⌘K
RIGHT ANGLE D-SUB CONNECTOR ROHS COMPLIANT: YES
| Part | Dielectric Material | Operating Temperature [Min] | Operating Temperature [Max] | Contact Material | Features | Shell Size, Connector Layout | Shell Size, Connector Layout | Contact Type | Number of Rows [custom] | Number of Positions | Connector Type | Backset Spacing | Backset Spacing | Flange Feature | Flange Feature | Current Rating (Amps) | Mounting Type | Termination | Material Flammability Rating | Shell Material, Finish | Contact Finish Thickness | Contact Finish Thickness | Contact Finish | Connector Style | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | -55 C | 85 °C | Copper Alloy | Mounting Brackets Shielded | C DC | 4 | Signal | 3 | 62 | Receptacle Female Sockets | 8.89 mm | 0.35 in | Housing/Shell | 4-40 | 3 A | Board Edge Right Angle Through Hole | Solder | UL94 V-0 | Nickel Plated Steel | 0.38 µm | 15 µin | Gold | D-Sub High Density | |
 EDAC Inc. | Polyester Thermoplastic | -55 C | 125 °C | Copper Alloy | Board Lock Mounting Brackets Shielded | C DC | 4 | Signal | 3 | 62 | Receptacle Female Sockets | 8.89 mm | 0.35 in | Housing/Shell (Unthreaded) | 3 A | Board Edge Right Angle Through Hole | Solder | UL94 V-0 | Nickel Plated Steel | 0.76 Ám | 30 Áin | Gold | D-Sub High Density | ||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 85 °C | Copper Alloy | Mounting Brackets Shielded | C DC | 4 | Signal | 3 | 62 | Receptacle Female Sockets | 8.89 mm | 0.35 in | Housing/Shell | 4-40 | 3 A | Board Edge Right Angle Through Hole | Solder | UL94 V-0 | Nickel Plated Steel | Gold | D-Sub High Density | Flash | ||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 125 °C | Copper Alloy | Board Lock Mounting Brackets Shielded | C DC | 4 | Signal | 3 | 62 | Receptacle Female Sockets | 8.89 mm | 0.35 in | Housing/Shell | 4-40 | 3 A | Board Edge Right Angle Through Hole | Solder | UL94 V-0 | Nickel Plated Steel | Gold | D-Sub High Density | Flash | ||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 85 °C | Copper Alloy | Board Lock Mounting Brackets Shielded | C DC | 4 | Signal | 3 | 62 | Receptacle Female Sockets | 8.89 mm | 0.35 in | Housing/Shell | 4-40 | 3 A | Board Edge Right Angle Through Hole | Solder | UL94 V-0 | Nickel Plated Steel | Gold | D-Sub High Density | Flash | ||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 125 °C | Copper Alloy | Board Lock Mounting Brackets Shielded | C DC | 4 | Signal | 3 | 62 | Receptacle Female Sockets | 8.89 mm | 0.35 in | Housing/Shell (Unthreaded) | 3 A | Board Edge Right Angle Through Hole | Solder | UL94 V-0 | Nickel Plated Steel | Gold | D-Sub High Density | Flash | |||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 125 °C | Copper Alloy | Board Lock Mounting Brackets Shielded | C DC | 4 | Signal | 3 | 62 | Receptacle Female Sockets | 8.89 mm | 0.35 in | Housing/Shell (M3) | 3 A | Board Edge Right Angle Through Hole | Solder | UL94 V-0 | Nickel Plated Steel | 0.38 µm | 15 µin | Gold | D-Sub High Density | ||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 85 °C | Copper Alloy | Board Lock Mounting Brackets Shielded | C DC | 4 | Signal | 3 | 62 | Receptacle Female Sockets | 8.89 mm | 0.35 in | Housing/Shell (M3) | 3 A | Board Edge Right Angle Through Hole | Solder | UL94 V-0 | Nickel Plated Steel | 0.76 Ám | 30 Áin | Gold | D-Sub High Density | ||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 125 °C | Copper Alloy | Board Lock Mounting Brackets Shielded | C DC | 4 | Signal | 3 | 62 | Receptacle Female Sockets | 8.89 mm | 0.35 in | Housing/Shell (M3) | 3 A | Board Edge Right Angle Through Hole | Solder | UL94 V-0 | Nickel Plated Steel | Gold | D-Sub High Density | Flash | |||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 85 °C | Copper Alloy | Board Lock Mounting Brackets Shielded | C DC | 4 | Signal | 3 | 62 | Receptacle Female Sockets | 8.89 mm | 0.35 in | 4-40 | 3 A | Board Edge Right Angle Through Hole | Solder | UL94 V-0 | Nickel Plated Steel | 0.76 Ám | 30 Áin | Gold | D-Sub High Density |
