BT1M Series

Catalog

CABLE TIE, DOME TOP® BARB TY, NYLON 6.6 (POLYAMIDE 6.6), BLACK, 102 MM, 2.4 MM, 23 MM, 18 LB

Part	Tensile Strength	Tensile Strength	Mounting Type	Wire/Cable Tie Type	Length - Approximate [x]	Width	Width	Material	Shelf Life Start	Bundle Diameter [diameter]	Bundle Diameter [diameter]	Length - Actual	Length - Actual	Length - Actual	Color	Features	Shelf Life
Panduit Corp BT1M-C0	18 lbs	8.16 kg	Free Hanging (In-Line)	Locking Standard	4 in	2.41 mm	0.095 in	Polyamide (PA66) Nylon 6/6	Date of Manufacture	0.9 "	22.86 mm	0.333 ft	101.6 mm	4 in	Black	Weather Resistant	48 Months
Panduit Corp BT1M-M30	18 lbs	8.16 kg	Free Hanging (In-Line)	Locking Standard	4 in	2.41 mm	0.095 in	Polyamide (PA66) Nylon 6/6	Date of Manufacture	0.9 "	22.86 mm	0.333 ft	101.6 mm	4 in	Black	Heat Stabilized	48 Months
Panduit Corp BT1M-MP
Panduit Corp BT1M-M3	18 lbs	8.16 kg	Free Hanging (In-Line)	Locking Standard	4 in	2.41 mm	0.095 in	Polyamide (PA66) Nylon 6/6		0.9 "	22.86 mm	0.333 ft	101.6 mm	4 in
Panduit Corp BT1M-C30	18 lbs	8.16 kg	Free Hanging (In-Line)	Locking Standard	4 in	2.41 mm	0.095 in	Polyamide (PA66) Nylon 6/6		0.9 "	22.86 mm	0.333 ft	101.6 mm	4 in	Black	Heat Stabilized
Panduit Corp BT1M-M10	18 lbs	8.16 kg	Free Hanging (In-Line)	Locking Standard	4 in	2.41 mm	0.095 in	Polyamide (PA66) Nylon 6/6		0.9 "	22.86 mm	0.333 ft	101.6 mm	4 in	White
Panduit Corp BT1M-C	18 lbs	8.16 kg	Free Hanging (In-Line)	Locking Standard	4 in	2.41 mm	0.095 in	Polyamide (PA66) Nylon 6/6	Date of Manufacture	0.9 "	22.86 mm	0.333 ft	101.6 mm	4 in	Natural		48 Months
Panduit Corp BT1M-CGM
Panduit Corp BT1M-M2	18 lbs	8.16 kg	Free Hanging (In-Line)	Locking Standard	4 in	2.41 mm	0.095 in	Polyamide (PA66) Nylon 6/6		0.9 "	22.86 mm	0.333 ft	101.6 mm	4 in	Red
Panduit Corp BT1M-M39	18 lbs	8.16 kg	Free Hanging (In-Line)	Locking Standard	4 in	2.41 mm	0.095 in	Polyamide (PA66) Nylon 6/6	Date of Manufacture	0.9 "	22.86 mm	0.333 ft	101.6 mm	4 in	Natural	Heat Stabilized	48 Months
