TPS22929D Series

5.5-V, 1.8-A, 115-mΩ load switch with output discharge

Catalog

5.5-V, 1.8-A, 115-mΩ load switch with output discharge

Part	Supplied Contents	Type	Utilized IC / Part	Function	Output Configuration	Switch Type	Fault Protection	Supplier Device Package	Mounting Type	Number of Outputs	Voltage - Load [Max]	Voltage - Load [Min]	Features	Interface	Current - Output (Max) [Max]	Package / Case	Input Type	Ratio - Input:Output [custom]	Rds On (Typ)	Output Type	Operating Temperature [Max]	Operating Temperature [Min]
Texas Instruments TPS22929DEVM-661	Board(s)	Power Management	TPS22929D	Power Distribution Switch (Load Switch)
Texas Instruments TPS22929DDBVR					High Side	General Purpose	Reverse Current UVLO	SOT-23-6	Surface Mount	1	5.5 V	1.4 V	Load Discharge Slew Rate Controlled	On/Off	1.8 A	SOT-23-6	Non-Inverting	1:1	115 mOhm	P-Channel	85 °C	-40 °C
Texas Instruments TPS22929DDBVT					High Side	General Purpose	Reverse Current UVLO	SOT-23-6	Surface Mount	1	5.5 V	1.4 V	Load Discharge Slew Rate Controlled	On/Off	1.8 A	SOT-23-6	Non-Inverting	1:1	115 mOhm	P-Channel	85 °C	-40 °C

Catalog

5.5-V, 1.8-A, 115-mΩ load switch with output discharge

Key Features

• Integrated Single Load SwitchSmall SOT23-6 PackageInput Voltage Range: 1.4 V to 5.5 VLow ON-ResistancerON= 115 mΩ at VIN = 5 VrON= 115 mΩ at VIN = 3.3 VrON= 118 mΩ at VIN = 2.5 VrON= 129 mΩ at VIN = 1.5 V1.8-A Continuous Switch Current (25°C)Low Threshold Control InputControlled Slew-rateUnder-Voltage Lock OutQuick Output DischargeReverse Current ProtectionIntegrated Single Load SwitchSmall SOT23-6 PackageInput Voltage Range: 1.4 V to 5.5 VLow ON-ResistancerON= 115 mΩ at VIN = 5 VrON= 115 mΩ at VIN = 3.3 VrON= 118 mΩ at VIN = 2.5 VrON= 129 mΩ at VIN = 1.5 V1.8-A Continuous Switch Current (25°C)Low Threshold Control InputControlled Slew-rateUnder-Voltage Lock OutQuick Output DischargeReverse Current Protection

Description

The TPS22929D is a small, low rONload switch with controlled turn on. The device contains a P-channel MOSFET that can operate over an input voltage range of 1.4 V to 5.5 V. The switch is controlled by an on/off input (ON), which is capable of interfacing directly with low-voltage control signals. The TPS22929D is active high enable. The TPS22929D contains a 150-Ω on-chip load resistor for quick output discharge when the switch is turned off. The rise time of the device is internally controlled in order to avoid inrush current. The TPS22929D device provides circuit breaker functionality by latching off the power-switch during reverse voltage situations. An internal reverse voltage comparator disables the power-switch when the output voltage (VOUT) is driven higher than the input (VIN) to quickly (10 µs typ) stop the flow of current towards the input side of the switch. Reverse current is always active, even when the power-switch is disabled. Additionally, under-voltage lockout (UVLO) protection turns the switch off if the input voltage is too low. The TPS22929D is available in a small, space-saving 6-pin SOT23 package and is characterized for operation over the free-air temperature range of –40°C to 85°C. The TPS22929D is a small, low rONload switch with controlled turn on. The device contains a P-channel MOSFET that can operate over an input voltage range of 1.4 V to 5.5 V. The switch is controlled by an on/off input (ON), which is capable of interfacing directly with low-voltage control signals. The TPS22929D is active high enable. The TPS22929D contains a 150-Ω on-chip load resistor for quick output discharge when the switch is turned off. The rise time of the device is internally controlled in order to avoid inrush current. The TPS22929D device provides circuit breaker functionality by latching off the power-switch during reverse voltage situations. An internal reverse voltage comparator disables the power-switch when the output voltage (VOUT) is driven higher than the input (VIN) to quickly (10 µs typ) stop the flow of current towards the input side of the switch. Reverse current is always active, even when the power-switch is disabled. Additionally, under-voltage lockout (UVLO) protection turns the switch off if the input voltage is too low. The TPS22929D is available in a small, space-saving 6-pin SOT23 package and is characterized for operation over the free-air temperature range of –40°C to 85°C.
