UM30 Series
Manufacturer: SICK, Inc.
Beta
⌘K
SENSOR PROX ULTRA 200-1300MM CYL
| Part | Sensor Type | Indicator | Material - Body | Voltage - Supply [Min] | Voltage - Supply [Max] | Operating Temperature [Min] | Operating Temperature [Max] | Output Type | Termination Style | Sensing Distance [Min] | Sensing Distance [Min] | Sensing Distance [Max] | Sensing Distance [Max] | Ingress Protection | Response Frequency | Package / Case |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 SICK, Inc. | Ultrasonic | LED | Nickel-Plated Brass Polybutylene Terephthalate (PBT) | 9 V | 30 VDC | -25 °C | 70 °C | PNP | Connector | 20 cm | 7.874 in | 1300 mm | 51.181 in | IP67 | 8 Hz | Cylinder Threaded - M30 |
SICK, Inc. | Ultrasonic | LED | Nickel-Plated Brass Polybutylene Terephthalate (PBT) | 9 V | 30 VDC | -25 °C | 70 °C | NPN | Connector | 600 mm | 23.622 in | 6 m | 236.22 " | IP67 | 3 Hz | Cylinder Threaded - M30 |
 SICK, Inc. | Ultrasonic | LED | Nickel-Plated Brass Polybutylene Terephthalate (PBT) | 9 V | 30 VDC | -25 °C | 70 °C | PNP | Connector | 65 mm | 2.559 in | 350 mm | 13.78 " | IP67 | 12 Hz | Cylinder Threaded - M30 |
SICK, Inc. | Ultrasonic | LED | Nickel-Plated Brass Polybutylene Terephthalate (PBT) | 9 V | 30 VDC | -25 °C | 70 °C | NPN | Connector | 30 mm | 1.181 in | 250 mm | 9.843 " | IP67 | 25 Hz | Cylinder Threaded - M30 |
 SICK, Inc. | Ultrasonic | LED | Nickel-Plated Brass Polybutylene Terephthalate (PBT) | 9 V | 30 VDC | -25 °C | 70 °C | NPN | Connector | 65 mm | 2.559 in | 350 mm | 13.78 " | IP67 | 12 Hz | Cylinder Threaded - M30 |
 SICK, Inc. | Ultrasonic | LED | Nickel-Plated Brass Polybutylene Terephthalate (PBT) | 9 V | 30 VDC | -25 °C | 70 °C | PNP | Connector | 600 mm | 23.622 in | 6 m | 236.22 " | IP67 | 3 Hz | Cylinder Threaded - M30 |
 SICK, Inc. | Ultrasonic | LED | Nickel-Plated Brass Polybutylene Terephthalate (PBT) | 9 V | 30 VDC | -25 °C | 70 °C | NPN | Connector | 600 mm | 23.622 in | 6 m | 236.22 " | IP67 | 3 Hz | Cylinder Threaded - M30 |
 SICK, Inc. | Ultrasonic | LED | Nickel-Plated Brass Polybutylene Terephthalate (PBT) | 9 V | 30 VDC | -25 °C | 70 °C | NPN | Connector | 20 cm | 7.874 in | 1300 mm | 51.181 in | IP67 | 8 Hz | Cylinder Threaded - M30 |
SICK, Inc. | Ultrasonic | LED | Nickel-Plated Brass Polybutylene Terephthalate (PBT) | 9 V | 30 VDC | -25 °C | 70 °C | NPN | Connector | 20 cm | 7.874 in | 1300 mm | 51.181 in | IP67 | 8 Hz | Cylinder Threaded - M30 |
SICK, Inc. | Ultrasonic | LED | Nickel-Plated Brass Polybutylene Terephthalate (PBT) | 9 V 15 VDC | 30 VDC | -25 °C | 70 °C | Analog Current and Voltage PNP | Connector | 30 mm | 1.181 in | 250 mm | 9.843 " | IP67 | 25 Hz | Cylinder Threaded - M30 |
