ELSH-Q61 Series
Manufacturer: Everlight Electronics Co Ltd
Beta
⌘K
LED SHUEN RED 730NM SMD
| Part | Thermal Resistance of Package | Current - Max [Max] | Color | Viewing Angle | Voltage - Forward (Vf) (Typ) | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [y] | Luminous Flux @ Current/Temperature [Max] | Luminous Flux @ Current/Temperature [Min] | Luminous Flux @ Current/Temperature | Mounting Type | Wavelength [Min] | Wavelength | Wavelength [Max] | Temperature - Test | Height - Seated (Max) [Max] | Height - Seated (Max) | Supplier Device Package | Package / Case | Current - Test |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Everlight Electronics Co Ltd | 12 °C/W | 600 mA | Red | 120 ° | 2.35 V | 0.12 inches | 4.5 mm | 3.05 mm | 0.177 " | 175 mW | 125 mW | 150 mW | Surface Mount | 715 nm | 730 nm | 745 nm | 25 °C | 0.085 in | 2.15 mm | SMD | 1218 (3246 Metric) | 350 mA |
