BAS70-04L Series

70 mA, 70 V, Schottky Diode, Dual, Series

Catalog

70 mA, 70 V, Schottky Diode, Dual, Series

Part	Technology	Current - Average Rectified (Io)	Voltage - DC Reverse (Vr) (Max) [Max]	Operating Temperature - Junction [Max]	Operating Temperature - Junction [Min]	Mounting Type	Voltage - Forward (Vf) (Max) @ If	Package / Case	Capacitance @ Vr, F	Current - Reverse Leakage @ Vr	Speed	Speed	Reverse Recovery Time (trr)	Current - Average Rectified (Io) (per Diode)	Diode Configuration	Supplier Device Package
ON Semiconductor BAS70SL	Schottky	70 mA	70 V	150 °C	-55 °C	Surface Mount	1 V	SOD-923	3 pF	200 nA	Any Speed	200 mA	8 ns
ON Semiconductor BAS70-04LT1G	Schottky		70 V	150 °C	-55 °C	Surface Mount	1 V	SC-59 SOT-23-3 TO-236-3		10 µA	Any Speed	200 mA		100 mA	1 Pair Series Connection	SOT-23-3 (TO-236)
ON Semiconductor BAS70SV	Schottky		70 V	150 °C	-55 °C	Surface Mount	1 V	SOT-563 SOT-666		2.5 µA	Any Speed	200 mA	8 ns		2 Independent	SOT-563F
ON Semiconductor BAS70-04LT1	Schottky		70 V			Surface Mount	1 V	SC-59 SOT-23-3 TO-236-3		10 µA	Any Speed	200 mA			1 Pair Series Connection	SOT-23-3 (TO-236)

Catalog

70 mA, 70 V, Schottky Diode, Dual, Series

Key Features

• Extremely Fast Switching Speed

• Low Forward Voltage 0.75 Volts (Typ) @ IF= 10 mAdc

• S and NSV Prefix for Automotive and Other Applications Requiring Unique Site and Control Change Requirements; AECQ101 Qualified and PPAP Capable

Description

The Schottky diode is designed for high speed switching applications, circuit protection and voltage clamping. Extremely low forward voltage reduces conduction loss. The miniature surface mount package is excellent for hand held and portable applications, where space is limited.
