307-054 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 54POS 0.156
| Part | Termination Rows [custom] | Material - Insulation | Contact Finish | Card Thickness [Max] | Card Thickness [Min] | Card Type | Contact Material | Read Out | Color | Contact Type | Number of Positions/Bay/Row | Gender | Pitch | Pitch | Number of Positions | Number of Rows [custom] | Operating Temperature [Min] | Operating Temperature [Max] | Termination | Mounting Type | Flange Feature | Contact Finish Thickness | Contact Finish Thickness | Flange Feature [diameter] | Flange Feature [diameter] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyester Thermoplastic | Tin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Copper Alloy | Dual | Green | Semi Bellows | 27 | Female | 3.96 mm | 0.156 in | 54 | 2 | -40 C | 105 ░C | Solder | Board Edge Straddle Mount | ||||||
 EDAC Inc. | 2 | Polyester Thermoplastic | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Copper Alloy | Dual | Green | Semi Bellows | 27 | Female | 3.96 mm | 0.156 in | 54 | 2 | -40 C | 105 ░C | Solder | Through Hole | Flush Mount M3 Threaded Insert Top Opening | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | 2 | Polyester Thermoplastic | Tin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Copper Alloy | Dual | Green | Semi Bellows | 27 | Female | 3.96 mm | 0.156 in | 54 | 2 | -40 C | 105 ░C | Solder | Through Hole | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | |||
 EDAC Inc. | 2 | Polyester Thermoplastic | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Copper Alloy | Dual | Green | Semi Bellows | 27 | Female | 3.96 mm | 0.156 in | 54 | 2 | -40 C | 105 ░C | Solder Eyelet(s) | Through Hole | Flush Mount M3 Threaded Insert Top Opening | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | 2 | Polyester Thermoplastic | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Copper Alloy | Dual | Green | Semi Bellows | 27 | Female | 3.96 mm | 0.156 in | 54 | 2 | -40 C | 105 ░C | Solder | Board Edge Straddle Mount | 4-40 Flush Mount Threaded Insert Top Opening | 0.25 Ám | 10 Áin | Card Extender Card Guides | ||
 EDAC Inc. | 2 | Polyester Thermoplastic | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Copper Alloy | Dual | Green | Semi Bellows | 27 | Female | 3.96 mm | 0.156 in | 54 | 2 | -40 C | 105 ░C | Solder | Through Hole | Flush Mount Top Opening Unthreaded | 0.25 Ám | 10 Áin | 0.156 " | 3.96 mm | |
 EDAC Inc. | 2 | Polyester Thermoplastic | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Copper Alloy | Dual | Green | Semi Bellows | 27 | Female | 3.96 mm | 0.156 in | 54 | 2 | -40 C | 105 ░C | Solder | Right Angle Through Hole | Flush Mount Side Opening Unthreaded | 0.25 Ám | 10 Áin | 0.128 " | 3.25 mm | |
 EDAC Inc. | 2 | Polyester Thermoplastic | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Copper Alloy | Dual | Green | Semi Bellows | 27 | Female | 3.96 mm | 0.156 in | 54 | 2 | -40 C | 105 ░C | Solder Eyelet(s) | Board Edge Straddle Mount | 0.25 Ám | 10 Áin | Card Extender | |||
 EDAC Inc. | 2 | Polyester Thermoplastic | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Copper Alloy | Dual | Green | Semi Bellows | 27 | Female | 3.96 mm | 0.156 in | 54 | 2 | -40 C | 105 ░C | Solder Wire Wrap | Right Angle Through Hole | Flush Mount Side Opening Unthreaded | 0.25 Ám | 10 Áin | 0.128 " | 3.25 mm | |
 EDAC Inc. | 2 | Polyester Thermoplastic | Tin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Copper Alloy | Dual | Green | Semi Bellows | 27 | Female | 3.96 mm | 0.156 in | 54 | 2 | -40 C | 105 ░C | Solder Eyelet(s) | Through Hole | 4-40 Flush Mount Threaded Insert Top Opening | Card Guides |
