E2E-X1 Series
Manufacturer: Omron Automation and Safety
Beta
⌘K
SENSOR INDUCT 1.5MM NPN M8 NO/NC
| Part | Voltage - Supply [Min] | Voltage - Supply [Max] | Indicator | Material - Body | Operating Temperature [Max] | Operating Temperature [Min] | Termination Style | Sensing Distance | Sensing Distance | Response Frequency | Output Type | Ingress Protection | Package / Case | Shielding | Sensor Type | Output Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Omron Automation and Safety | 10 VDC | 30 VDC | LED | Stainless Steel | 85 °C | -40 C | Connector | 1.5 mm | 0.059 in | 2 kHz | 3-Wire NPN-NC/NO | IP67 IP69K | Cylinder Threaded - M8 | Shielded | Inductive | |
Omron Automation and Safety | 10 VDC | 30 VDC | LED | Stainless Steel | 85 °C | -40 C | Cable Leads | 1.5 mm | 0.059 in | 2 kHz | 3-Wire NPN-NO | IP67 IP69K | Cylinder Threaded - M8 | Shielded | Inductive | |
 Omron Automation and Safety | 10 VDC | 40 VDC | LED | Stainless Steel | 85 °C | -40 C | Cable Leads | 1.5 mm | 0.059 in | 2 kHz | 3-Wire NPN-NO | IP67 | Cylinder Threaded - M8 | Shielded | Inductive | |
Omron Automation and Safety | 10 VDC | 30 VDC | LED | Stainless Steel | 70 °C | -25 °C | Cable with Connector | 1.5 mm | 0.059 in | 2 kHz | 3-Wire NPN-NO | IP67 IP69K | Cylinder Threaded - M8 | Shielded | Inductive | |
 Omron Automation and Safety | 10 VDC | 30 VDC | LED | Stainless Steel | 85 °C | -40 C | Cable Leads | 1.5 mm | 0.059 in | 2 kHz | 3-Wire NPN-NC | IP67 IP69K | Cylinder Threaded - M8 | Shielded | Inductive | |
Omron Automation and Safety | 10 VDC | 30 VDC | LED | Stainless Steel | 70 °C | -25 °C | Cable with Connector | 1.5 mm | 0.059 in | 2 kHz | PNP-NO | IP67 IP69K | Cylinder Threaded - M8 | Shielded | Inductive | 3 |
 Omron Automation and Safety | 10 VDC | 30 VDC | LED | Stainless Steel | 85 °C | -40 C | Connector | 1.5 mm | 0.059 in | 2 kHz | 3-Wire NPN-NO | IP67 IP69K | Cylinder Threaded - M8 | Shielded | Inductive | |
Omron Automation and Safety | 10 VDC | 30 VDC | LED | Stainless Steel | 85 °C | -40 C | Connector | 1.5 mm | 0.059 in | 2 kHz | PNP-NO | IP67 IP69K | Cylinder Threaded - M8 | Shielded | Inductive | 3 |
 Omron Automation and Safety | 10 VDC | 30 VDC | LED | Stainless Steel | 85 °C | -40 C | Cable Leads | 1.5 mm | 0.059 in | 2 kHz | 3-Wire NPN-NO | IP67 IP69K | Cylinder Threaded - M8 | Shielded | Inductive | |
Omron Automation and Safety | 10 VDC | 30 VDC | LED | Stainless Steel | 85 °C | -40 C | Cable Leads | 1.5 mm | 0.059 in | 2 kHz | PNP-NO | IP67 IP69K | Cylinder Threaded - M8 | Shielded | Inductive | 3 |
