307-029 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CARD EDGE CONNECTOR, SINGLE SIDE, 1.57 MM, 29 CONTACTS, THROUGH HOLE MOUNT, RIGHT ANGLE
| Part | Material - Insulation | Termination Rows | Gender | Card Type | Contact Type | Contact Material | Termination | Number of Rows | Operating Temperature [Min] | Operating Temperature [Max] | Contact Finish | Number of Positions | Features | Mounting Type | Card Thickness [Max] | Card Thickness [Min] | Number of Positions/Bay/Row | Flange Feature | Color | Pitch | Pitch | Read Out | Contact Finish Thickness | Contact Finish Thickness | Flange Feature [diameter] | Flange Feature [diameter] | Number of Rows [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 1 | Female | Non Specified - Single Edge | Semi Bellows | Copper Alloy | Solder | 1 | -40 C | 105 ░C | Tin | 29 | Card Guides | Right Angle Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 29 | 4-40 Flush Mount Threaded Insert Top Opening | Green | 3.96 mm | 0.156 in | Single | |||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Female | Non Specified - Single Edge | Semi Bellows | Copper Alloy | Wire Wrap | 1 | -40 C | 105 ░C | Gold | 29 | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 29 | Flush Mount M3 Threaded Insert Top Opening | Green | 3.96 mm | 0.156 in | Single | 0.25 Ám | 10 Áin | ||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Female | Non Specified - Single Edge | Semi Bellows | Copper Alloy | Solder | 1 | -40 C | 105 ░C | Tin | 29 | Right Angle Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 29 | Flush Mount Top Opening Unthreaded | Green | 3.96 mm | 0.156 in | Single | 3.25 mm | 0.128 " | ||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Female | Non Specified - Dual Edge | Semi Bellows | Copper Alloy | Solder Eyelet(s) | -40 C | 105 ░C | Gold | 58 | Surface Mount | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 29 | Flush Mount Top Opening Unthreaded | Green | 3.96 mm | 0.156 in | Dual | 0.25 Ám | 10 Áin | 3.25 mm | 0.128 " | 2 | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Female | Non Specified - Dual Edge | Semi Bellows | Copper Alloy | Solder Eyelet(s) | -40 C | 105 ░C | Gold | 58 | Surface Mount | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 29 | Flush Mount Side Opening Unthreaded | Green | 3.96 mm | 0.156 in | Dual | 0.25 Ám | 10 Áin | 3.25 mm | 0.128 " | 2 | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Female | Non Specified - Single Edge | Semi Bellows | Copper Alloy | Wire Wrap | 1 | -40 C | 105 ░C | Gold | 29 | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 29 | Floating Bobbin Flush Mount | Green | 3.96 mm | 0.156 in | Single | 0.25 Ám | 10 Áin | 2.95 mm | 0.116 " | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Female | Non Specified - Dual Edge | Semi Bellows | Copper Alloy | Solder | -40 C | 105 ░C | Tin | 58 | Right Angle Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 29 | Floating Bobbin Flush Mount | Green | 3.96 mm | 0.156 in | Dual | 2.95 mm | 0.116 " | 2 | ||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Female | Non Specified - Single Edge | Semi Bellows | Copper Alloy | Solder | 1 | -40 C | 105 ░C | Gold | 29 | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 29 | Floating Bobbin Flush Mount | Green | 3.96 mm | 0.156 in | Single | 0.25 Ám | 10 Áin | 2.95 mm | 0.116 " | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Female | Non Specified - Single Edge | Semi Bellows | Copper Alloy | Solder | 1 | -40 C | 105 ░C | Tin | 29 | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 29 | Flush Mount Top Opening Unthreaded | Green | 3.96 mm | 0.156 in | Single | 3.96 mm | 0.156 " | ||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Female | Non Specified - Single Edge | Semi Bellows | Copper Alloy | Solder | 1 | -40 C | 105 ░C | Tin | 29 | Right Angle Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 29 | Floating Bobbin Flush Mount | Green | 3.96 mm | 0.156 in | Single | 2.95 mm | 0.116 " |
