FSA2567 Series

Low Power, Dual SIM Card Analog Switch

Catalog

Low Power, Dual SIM Card Analog Switch

Part	Features	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Supply, Single (V+) [Max]	Voltage - Supply, Single (V+) [Min]	Mounting Type	Number of Channels	-3db Bandwidth	Package / Case	On-State Resistance (Max) [Max]	Switch Circuit	Supplier Device Package	Applications
ON Semiconductor FSA2567MPX	Break-Before-Make	85 °C	-40 °C	4.3 V	1.65 V	Surface Mount	1	475 MHz	16-WFQFN Exposed Pad	10 Ohms	4PDT	16-MLP (3x3)	Telecommunications
ON Semiconductor FSA2567MPX	Break-Before-Make	85 °C	-40 °C	4.3 V	1.65 V	Surface Mount	1	475 MHz	16-WFQFN Exposed Pad	10 Ohms	4PDT	16-MLP (3x3)	Telecommunications
ON Semiconductor FSA2567UMX	Break-Before-Make	85 °C	-40 °C	4.3 V	1.65 V	Surface Mount	1	475 MHz	16-UFQFN	10 Ohms	4PDT	16-UMLP (1.8x2.6)	Telecommunications
ON Semiconductor FSA2567UMX	Break-Before-Make	85 °C	-40 °C	4.3 V	1.65 V	Surface Mount	1	475 MHz	16-UFQFN	10 Ohms	4PDT	16-UMLP (1.8x2.6)	Telecommunications

Catalog

Low Power, Dual SIM Card Analog Switch

Key Features

• Low On Capacitance for Data Path: 10pF Typical

• Low On Resistance for Data Path: 6Ω Typical

• Low On Resistance for Supply Path 0.4Ω Typical

• Low Power Quiescent Consumption: 1µA Maximum

• 15µA Maximum ICCTOver Expanded Voltage Range (VIN=1.8V, VCC=4.3V)

• Wide -3db Bandwidth: > 160MHz

• Packaged in:

• Pb-free 16-Lead MLP

• Pb-free 16-Lead UMLP (1.8 x 2.6mm)

• 3kV ESD Rating, >12kV Power/GND ESD Rating

Description

The FSA2567 is a bi-directional, low-power, dual double-pole, double-throw (4PDT) analog switch targeted at dual SIM card multiplexing. It is optimized for switching the WLAN-SIM data and control signals and dedicates one channel as a supply-source switch. The FSA2567 is compatible with the requirements of SIM cards and features a low on capacitance (CON) of 10pF to ensure high-speed data transfer. The VSIMswitch path has a low RONcharacteristic to ensure minimal voltage drop in the dual SIM card supply paths. The FSA2567 contains special circuitry that minimizes current consumption when the control voltage applied to the SEL pin is lower than the supply voltage (VCC). This feature is especially valuable in ultra-portable applications, such as cell phones; allowing direct interface with the general-purpose I/Os of the baseband processor. Other applications include switching and connector sharing in portable cell phones, PDAs, digital cameras, printers, and notebook computers.
