807-010 Series
Manufacturer: EDAC Inc.
Catalog
CONN EDGE DUAL FMALE 20POS 0.156
...
| Part | Read Out | Operating Temperature [Max] | Operating Temperature [Min] | Gender | Material - Insulation | Color | Contact Finish | Contact Material | Card Thickness [Min] | Card Thickness [Min] | Card Thickness [Max] | Card Thickness [Max] | Contact Type | Mounting Type | Pitch [x] | Pitch [x] | Flange Feature | Number of Positions/Bay/Row [custom] | Termination | Number of Positions | Card Type | Contact Finish Thickness | Contact Finish Thickness | Termination Rows | Number of Rows | Flange Feature [diameter] | Flange Feature [diameter] | Flange Feature | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Dual | 125 °C | -40 °C | Female | Diallyl Phthalate (DAP) | Green | Gold | Copper Alloy | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Semi Bellows | Through Hole | 0.156 in | 3.96 mm | 4-40 Flush Mount Threaded Insert Top Opening | 10 | Solder | 20 | Non Specified - Dual Edge | 10 Áin | 0.25 Ám | 1 | 2 | ||||
 EDAC Inc. | Single | 125 °C | -40 °C | Female | Diallyl Phthalate (DAP) | Green | Gold | Copper Alloy | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Semi Bellows | Through Hole | 0.156 in | 3.96 mm | 10 | Solder | 10 | Non Specified - Single Edge | 10 Áin | 0.25 Ám | 1 | 1 | |||||
 EDAC Inc. | Single | 125 °C | -40 °C | Female | Diallyl Phthalate (DAP) | Green | Gold | Copper Alloy | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Semi Bellows | Through Hole Right Angle | 0.156 in | 3.96 mm | 4-40 Flush Mount Threaded Insert Top Opening | 10 | Solder | 10 | Non Specified - Single Edge | 10 Áin | 0.25 Ám | 1 | 1 | ||||
 EDAC Inc. | Single | 125 °C | -40 °C | Female | Diallyl Phthalate (DAP) | Green | Tin | Copper Alloy | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Semi Bellows | Through Hole | 0.156 in | 3.96 mm | Flush Mount Top Opening Unthreaded | 10 | Solder | 10 | Non Specified - Single Edge | 1 | 1 | 3.96 mm | 0.156 in | ||||
 EDAC Inc. | Dual | 125 °C | -40 °C | Female | Diallyl Phthalate (DAP) | Green | Gold | Copper Alloy | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Semi Bellows | Through Hole | 0.156 in | 3.96 mm | Side Mount Opening Unthreaded | 10 | Solder | 20 | Non Specified - Dual Edge | 10 Áin | 0.25 Ám | 1 | 2 | 3.25 mm | 0.128 in | ||
 EDAC Inc. | Dual | 125 °C | -40 °C | Female | Diallyl Phthalate (DAP) | Green | Gold | Copper Alloy | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Semi Bellows | Through Hole | 0.156 in | 3.96 mm | Flush Mount Top Opening Unthreaded | 10 | Solder | 20 | Non Specified - Dual Edge | 10 Áin | 0.25 Ám | 1 | 2 | 3.25 mm | 0.128 " | ||
 EDAC Inc. | Dual | 125 °C | -40 °C | Female | Diallyl Phthalate (DAP) | Green | Tin | Copper Alloy | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Semi Bellows | Through Hole | 0.156 in | 3.96 mm | 4-40 Flush Mount Threaded Insert Top Opening | 10 | Solder | 20 | Non Specified - Dual Edge | 1 | 2 | ||||||
 EDAC Inc. | Dual | 125 °C | -40 °C | Female | Diallyl Phthalate (DAP) | Green | Tin | Copper Alloy | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Semi Bellows | Through Hole | 0.156 in | 3.96 mm | Flush Mount Top Opening Unthreaded | 10 | Solder | 20 | Non Specified - Dual Edge | 1 | 2 | 3.25 mm | 0.128 " | ||||
 EDAC Inc. | Dual | 125 °C | -40 °C | Female | Diallyl Phthalate (DAP) | Green | Tin | Copper Alloy | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Semi Bellows | Through Hole | 0.156 in | 3.96 mm | Flush Mount Top Opening Unthreaded | 10 | Solder | 20 | Non Specified - Dual Edge | 1 | 2 | 3.96 mm | 0.156 in | ||||
 EDAC Inc. | Dual | 125 °C | -40 °C | Female | Diallyl Phthalate (DAP) | Green | Gold | Copper Alloy | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Semi Bellows | Through Hole | 0.156 in | 3.96 mm | Floating Bobbin Flush Mount | 10 | Solder Eyelet(s) | 20 | Non Specified - Dual Edge | 10 Áin | 0.25 Ám | 1 | 2 | 2.95 mm | 0.116 in |
