ICB12 Series
Manufacturer: Carlo Gavazzi Inc.
Beta
⌘K
PROXIMITY SENSORS INDUCTIVE PROXIMITY SENSOR, M12 NICKEL-PLATED BRASS, M12 PLUG, SN 10MM, NON-FLUSH MOUNT, SHORT BODY, PNP NO OUTPUT, SUPPLY VOLTAGE 10-36VDC, MAX OUTPUT CURRENT 200 MA, MAX SWITCHING FREQUENCY 2 KHZ, OPERATING TEMPERATURE -25C - +70C, IP67
| Part | Operating Temperature [Min] | Operating Temperature [Max] | Output Type | Indicator | Sensor Type | Termination Style | Shielding | Ingress Protection | Voltage - Supply [Max] | Voltage - Supply [Min] | Response Frequency | Material - Body | Sensing Distance | Sensing Distance | Package / Case | Output Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Carlo Gavazzi Inc. | -25 °C | 70 °C | 4-Wire PNP-NO | LED | Inductive | Connector | Unshielded | IP67 | 36 V | 10 VDC | 2 kHz | Nickel-Plated Brass | 10 mm | 0.394 in | Cylinder Threaded - M12 | |
 Carlo Gavazzi Inc. | -25 °C | 70 °C | NPN-NO | LED | Inductive | Connector | Unshielded | IP67 | 36 V | 10 VDC | 2 kHz | Nickel-Plated Brass | 10 mm | 0.394 in | Cylinder Threaded - M12 | 4 Pole |
 Carlo Gavazzi Inc. | -25 °C | 70 °C | 4-Wire PNP-NO | LED | Inductive | Connector | Unshielded | IP67 | 36 V | 10 VDC | 2 kHz | Nickel-Plated Brass | 8 mm | 0.315 in | Cylinder Threaded - M12 | |
 Carlo Gavazzi Inc. | -25 °C | 70 °C | NPN-NO | LED | Inductive | Connector | Unshielded | IP67 | 36 V | 10 VDC | 2 kHz | Nickel-Plated Brass | 8 mm | 0.315 in | Cylinder Threaded - M12 | 4 Pole |
Carlo Gavazzi Inc. | -25 °C | 70 °C | 3-Wire NPN-NC | LED | Inductive | Connector | Unshielded | IP67 | 36 V | 10 VDC | 2 kHz | Nickel-Plated Brass | 10 mm | 0.394 in | Cylinder Threaded - M12 | |
 Carlo Gavazzi Inc. | -25 °C | 70 °C | 4-Wire NPN-NC | LED | Inductive | Connector | Unshielded | IP67 | 36 V | 10 VDC | 2 kHz | Nickel-Plated Brass | 2 mm | 0.079 in | Cylinder Threaded - M12 | |
 Carlo Gavazzi Inc. | -25 °C | 70 °C | 4-Wire PNP-NO | LED | Inductive | Connector | Unshielded | IP67 | 36 V | 10 VDC | 2 kHz | Nickel-Plated Brass | 2 mm | 0.079 in | Cylinder Threaded - M12 | |
 Carlo Gavazzi Inc. | -25 °C | 70 °C | 4-Wire NPN-NC | LED | Inductive | Cable Leads | Unshielded | IP67 | 36 V | 10 VDC | 2 kHz | Nickel-Plated Brass | 2 mm | 0.079 in | Cylinder Threaded - M12 | |
 Carlo Gavazzi Inc. | -25 °C | 70 °C | NPN-NO | LED | Inductive | Cable Leads | Unshielded | IP67 | 36 V | 10 VDC | 2 kHz | Nickel-Plated Brass | 4 mm | 0.157 in | Cylinder Threaded - M12 | 4 Pole |
 Carlo Gavazzi Inc. | -25 °C | 80 °C | 3-Wire NPN-NO | LED | Inductive | Cable Leads | Unshielded | IP67 | 36 V | 10 VDC | Nickel-Plated Brass | 4 mm | 0.157 in | Cylinder Threaded - M12 |
