SJ2-25 Series
Manufacturer: Same Sky (Formerly CUI Devices)
Beta
⌘K
AUDIO JACK, 2.5 MM, RT, 4 CONDUC
| Part | Shielding | Internal Switch(s) | Termination | Connector Type | Operating Temperature [Max] | Operating Temperature [Min] | Housing Material | Voltage - Rated | Industry Recognized Mating Diameter | Industry Recognized Mating Diameter | Industry Recognized Mating Diameter | Features | Contact Material | Actual Diameter [diameter] | Actual Diameter [diameter] | Number of Positions/Contacts [custom] | Number of Positions/Contacts [custom] | Body Color | Current Rating (Amps) | Signal Lines | Mating Length/Depth | Mating Length/Depth | Gender | Contact Material - Plating | Mounting Type | Internal Switch(s) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Same Sky (Formerly CUI Devices) | Unshielded | Solder | Phone Jack | 85 °C | -25 °C | Polyamide (PA10T) Nylon 10T | 12 VDC | 2.5 mm | 0.094 " | 3 /32" | Board Guide | Brass Copper Alloy | 2.6 mm | 0.102 in | 4 | 4 | Black | 1 A | Stereo (4 Conductor TRRS) | 11 mm | 0.433 in | Female | Gold | Right Angle Surface Mount | ||
 Same Sky (Formerly CUI Devices) | Unshielded | Solder | Phone Jack | 85 °C | -25 °C | 2.5 mm | 0.094 " | 3 /32" | Board Guide | 2.6 mm | 0.102 in | 5 | 6 | 5 Conductor (TRRRS) | Female | Right Angle Surface Mount | Single Switch | |||||||||
 Same Sky (Formerly CUI Devices) | Unshielded | Solder | Phone Jack | 85 °C | -25 °C | Polyamide (PA10T) Nylon 10T | 12 VDC | 2.5 mm | 0.094 " | 3 /32" | Board Guide | Brass Copper Alloy | 2.6 mm | 0.102 in | 4 | 4 | Black | 1 A | Stereo (4 Conductor TRRS) | 11 mm | 0.433 in | Female | Silver | Right Angle Surface Mount | ||
Same Sky (Formerly CUI Devices) | Unshielded | Solder | Phone Jack | 85 °C | -25 °C | Polyamide (PA10T) Nylon 10T | 12 VDC | 2.5 mm | 0.094 " | 3 /32" | Board Guide | Brass Copper Alloy | 2.6 mm | 0.102 in | 5 | 6 | Black | 1 A | 5 Conductor (TRRRS) | 11 mm | 0.433 in | Female | Gold Silver | Right Angle Surface Mount | Single Switch | |
 Same Sky (Formerly CUI Devices) | Unshielded | Solder | Phone Jack | 85 °C | -25 °C | Polyamide (PA10T) Nylon 10T | 12 VDC | 2.5 mm | 0.094 " | 3 /32" | Board Guide | Copper Alloy | 2.6 mm | 0.102 in | 4 | 5 | Black | 1 A | Stereo (4 Conductor TRRS) | 11 mm | 0.433 in | Female | Gold | Right Angle Surface Mount | Single Switch | |
 Same Sky (Formerly CUI Devices) | Unshielded | Solder | Phone Jack | 85 °C | -25 °C | Polyamide (PA10T) Nylon 10T | 12 VDC | 2.5 mm | 0.094 " | 3 /32" | Board Guide | Copper Alloy | 2.6 mm | 0.102 in | 4 | 4 | Black | 1 A | Stereo (4 Conductor TRRS) | 11 mm | 0.433 in | Female | Silver | Right Angle Surface Mount | ||
Same Sky (Formerly CUI Devices) | Unshielded | Solder | Phone Jack | 85 °C | -25 °C | Polyamide (PA10T) Nylon 10T | 12 VDC | 2.5 mm | 0.094 " | 3 /32" | Board Guide | Brass Copper Alloy | 2.6 mm | 0.102 in | 4 | 5 | Black | 1 A | Stereo (4 Conductor TRRS) | 11 mm | 0.433 in | Female | Gold | Right Angle Surface Mount | Single Switch | |
Same Sky (Formerly CUI Devices) | Unshielded | Solder | Phone Jack | 85 °C | -25 °C | Polyamide (PA10T) Nylon 10T | 12 VDC | 2.5 mm | 0.094 " | 3 /32" | Board Guide | Brass Copper Alloy | 2.6 mm | 0.102 in | 4 | 5 | Black | 1 A | Stereo (4 Conductor TRRS) | 11 mm | 0.433 in | Female | Gold | Right Angle Surface Mount | Single Switch | |
 Same Sky (Formerly CUI Devices) | Unshielded | Solder | Phone Jack | 85 °C | -25 °C | Polyamide (PA10T) Nylon 10T | 12 VDC | 2.5 mm | 0.094 " | 3 /32" | Board Guide | Copper Alloy | 2.6 mm | 0.102 in | 4 | 4 | Black | 1 A | Stereo (4 Conductor TRRS) | 11 mm | 0.433 in | Female | Gold | Right Angle Surface Mount | ||
 Same Sky (Formerly CUI Devices) | Unshielded | Solder | Phone Jack | 85 °C | -25 °C | 2.5 mm | 0.094 " | 3 /32" | Board Guide | 2.6 mm | 0.102 in | 4 | 4 | Stereo (4 Conductor TRRS) | Female | Right Angle Surface Mount |
