TPS725 Series

Catalog

1-A, ULTRA-LOW-DROPOUT VOLTAGE REGULATOR WITH ENABLE & RESET

Part	Package / Case	Output Configuration	Current - Supply (Max) [Max]	Voltage - Input (Max) [Max]	Number of Regulators	Control Features	Voltage - Output (Min/Fixed)	Current - Quiescent (Iq)	PSRR	Current - Output	Voltage Dropout (Max)	Supplier Device Package	Mounting Type	Protection Features	Operating Temperature [Max]	Operating Temperature [Min]	Voltage Dropout (Max) [Max]	Voltage - Output (Max) [Max]	Output Type
Texas Instruments TPS72515DCQ	SOT-223-6	Positive	325 µA	6 V	1	Enable Reset	1.5 V	225 µA	60 dB	1 A	0.32 V	SOT-223-6	Surface Mount	Over Current Over Temperature Reverse Polarity Under Voltage Lockout (UVLO)	125 °C	-40 C
Texas Instruments TPS72525DCQR	SOT-223-6	Positive	325 µA	6 V	1	Enable Reset	2.5 V	225 µA	60 dB	1 A		SOT-223-6	Surface Mount	Over Current Over Temperature Reverse Polarity Under Voltage Lockout (UVLO)	125 °C	-40 C	0.28 V
Texas Instruments TPS72515KTTR	D2PAK TO-263-6 TO-263BA	Positive	325 µA	6 V	1	Enable Reset	1.5 V	225 µA	60 dB	1 A	0.32 V	TO-263 (DDPAK-5)	Surface Mount	Over Current Over Temperature Reverse Polarity Under Voltage Lockout (UVLO)	125 °C	-40 C
Texas Instruments TPS72516DCQ	SOT-223-6	Positive	325 µA	6 V	1	Enable Reset	1.6 V	225 µA	60 dB	1 A	0.32 V	SOT-223-6	Surface Mount	Over Current Over Temperature Reverse Polarity Under Voltage Lockout (UVLO)	125 °C	-40 C
Texas Instruments TPS72518KTTR	D2PAK TO-263-6 TO-263BA	Positive	325 µA	6 V	1	Enable Reset	1.8 V	225 µA	60 dB	1 A	0.32 V	TO-263 (DDPAK-5)	Surface Mount	Over Current Over Temperature Reverse Polarity Under Voltage Lockout (UVLO)	125 °C	-40 C
Texas Instruments TPS72525DCQ	SOT-223-6	Positive	325 µA	6 V	1	Enable Reset	2.5 V	225 µA	60 dB	1 A		SOT-223-6	Surface Mount	Over Current Over Temperature Reverse Polarity Under Voltage Lockout (UVLO)	125 °C	-40 C	0.28 V
Texas Instruments TPS72515DCQR	SOT-223-6	Positive	325 µA	6 V	1	Enable Reset	1.5 V	225 µA	60 dB	1 A	0.32 V	SOT-223-6	Surface Mount	Over Current Over Temperature Reverse Polarity Under Voltage Lockout (UVLO)	125 °C	-40 C
Texas Instruments TPS72516KTTT	D2PAK TO-263-6 TO-263BA	Positive	325 µA	6 V	1	Enable Reset	1.6 V	225 µA	60 dB	1 A	0.32 V	TO-263 (DDPAK-5)	Surface Mount	Over Current Over Temperature Reverse Polarity Under Voltage Lockout (UVLO)	125 °C	-40 C
Texas Instruments TPS72516DCQR	SOT-223-6	Positive	325 µA	6 V	1	Enable Reset	1.6 V	225 µA	60 dB	1 A	0.32 V	SOT-223-6	Surface Mount	Over Current Over Temperature Reverse Polarity Under Voltage Lockout (UVLO)	125 °C	-40 C
Texas Instruments TPS72501DCQ	SOT-223-6	Positive	325 µA	6 V	1	Enable Reset	1.22 V	225 µA	60 dB	1 A		SOT-223-6	Surface Mount	Over Current Over Temperature Reverse Polarity Under Voltage Lockout (UVLO)	125 °C	-40 C	0.28 V	5.5 V	Adjustable
